Switchcraft SCAEPIJN ¼" Acoustic End Pin Input Jack (Stereo) for Gibson® Acoustic Guitars-Nickel

This seller has not set a shipping cost for Denmark. Please contact them to ask about shipping.

kr.204.60

Incl. VAT

+ Shipping

Only 1 left

Grab it before it's gone

Listed:over a month ago

Saves:0

Randy's | OEM Guitar Parts

Historic Gainesville, TX, United States

Our users rate Reverb

Report Listing to Reverb

** $7.50 SHIPPING w/ FREE COMBINED SHIPPING ** 1 part or 50, it's only $7.50 to ship! Reverb will adjust the cost at checkout. If you're charged extra, send us a message and we'll make sure you get taken care of.
Individual ¼" strap nut end-pin jacks offer the same trusted quality of a Switchcraft end-pin jack, plus the added functionality of a removable strap nut. This is ideal for acoustic guitar applications, eliminating the need to drill a second hole into the instrument for an output jack. The included handle and cable clamp ensure critical connections are protected, perfect for both OEM pickups or customizations. All hardware is included for easy installation. Fits Gibson®. Available in:

Gold 157G

Nickel 157

Configuration

Number of Conductors: 3

Product Line: Littel Jacks

Mounting Type: Panel

Mounting Feature: Special Strap Nut

Termination Style: Solder

Contact Plating: Nickel

Color: Gold

Locking: Non-Locking

Sealed: Not Sealed

Packaging Type: Bulk

Standard Connector Type: 1/4" Phone Jacks & Plugs

Jack-Plug Type: Jack

Special Feature: Thick Panel "End Pin" Jack

Electrical

Current Rating: 1 Amps

Circuit-Schematic: Single Open

Mechanical

Panel Thickness: 1.25 in

Environmental

Temperature Range: -55C to +85C

Shielding: Unshielded

Minimum Temperature: -55 C

Maxiumum Temperature: 85 C

Compliance

RoHS Compliant: Compliant

REACH Compliant: Compliant

Brand: Switchcraft

Material

Body Material: Copper Alloy

Body Plating: Nickel

Contact Material: Copper Alloy

Insert Material Type: Rigid Plastic Insulating Spacers

Terminal Material: Copper Alloy

Spring Material: Copper Alloy

Sleeve Material: Steel

Gold, Nickel SCAEPIJG * For more product information, additional images and spec sheets, visit our website @ randys.rocks ** CUSTOM ENGRAVING ** Personalize almost any guitar part we stock @ the Norlin® Custom Shop. Learn more @ randys.rocks

Promoted similar listings

Condition	Brand New (New) Brand New items are sold by an authorized dealer or original builder and include all original packaging.Learn more
Brand	Switchcraft
Model	Switchcraft ¼" Input Jack - Littel Thick Panel Mount w/ Strap Button (Stereo) - Fits Gibson® - 157G -
