The long-awaited desktop module of KORG’s next-generation analog synthesizer. Minilogue XD module is the new desktop module version of minilogue xd, the four-voice polyphonic analog synthesizer with a customizable digital multi-engine and built-in stereo digital effects. The desktop module is equipped with the same controllers as the keyboard version, making it a great choice not only as an additional sound module for your keyboard or DAW but also providing excellent performability, giving you an easy way to include an analog polyphonic synth in your setup. It's also equipped with a poly-chain function that lets you connect it with another minilogue xd or minilogue xd module so that the two units can operate as a polysynth with a total of up to eight voices in your studio or on stage. Add the sounds of the minilogue xd to your setup or system! The minilogue xd features a customizable open-source environment. The unit comes with 16 user oscillator slots and 16 user effect slots that you can customize. Oscillators and user programs that you’ve created with the SDK (Software Development Kit) can be loaded into the minilogue xd via the dedicated librarian software, as well as oscillators other users share online. What sounds can you create using the fusion of expanded digital oscillators with analog synthesis? Create original programs, share code, and participate in the user community. KORG even provides sample code to get you started.

Product Features

• 4-voice hybrid analog/digital synthesizer module
• 2 VCOs plus digital Multi Engine
• Studio-grade digital effects: modulation effects, reverb, and delay
• 16-step motion sequencer with Keyboard mode
• Micro tuning; Portamento knob
• Voice Mode Depth, Tempo knobs
• Joystick modifies different parameters for each program
• Poly Chain function lets 2 minilogue XD units play as an 8-voice polyphonic synth
• CV/Gate, Damper pedal inputs
• 1/4" stereo out, headphone jacks
• USB-to-host
• Included software bundle

Attributes

• Color: Black

Technical Specifications

• Type: Desktop Synthesizer
• Dimensions: 3.35" H x 19.69" W x 7.05" D
• Inputs: 1 x 1/4" (Damper), 2 x 1/8" (CV in), 1 x 1/8" (Sync in)
• Outputs: 1 x 1/4" (Headphones), 1 x 1/8" (Sync out)
• MIDI: In, Out, USB
• USB: 1 x Type B
• Effects: Chorus, Flanger, Phaser, Delay, Reverb
• Processing Type: Hybrid
• # of Presets: 200 factory, 300 user
• # of Pedal Inputs: 1
• Polyphony: 4 Notes
• Power Supply: 9V DC power supply (included)
• Pedal Input Type: Damper
• Arpeggiator: 4-voice with Latch mode
• Sequencer: 16-step Polyphonic Sequencer, Motion Sequence, Realtime Recording
• Controller: Joystick
• Oscillator: 2 x Analog VCO, 1 x Digital (noise, vpm, user)
• Filter: Sharp Two-pole
• Waveform: Sawtooth, Triangle, Square
