The DBR10 is the most compact model in its series and in its class. Capable of delivering a maximum SPL of 129dB from its compact enclosure, the DBR10 can be used as a utility speaker in a variety of environments. Wherever your music may take you, DBR Series loudspeakers are up to the task of delivering powerful, high-quality sound with an un-matched economy of transport and setup time. The most portable powered loudspeakers Yamaha has to offer, the versatile DBR Series harnesses the same state-of-the-art Yamaha DSP and amplifier and speaker technologies developed for the professional DSR Series and DXR Series lineups, ensuring high-resolution sound at any output level. Comprised of 10”, 12” and 15” models, each DBR loudseaker is housed in a newly designed, durable, lightweight cabinet optimized for FOH sound, floor-monitoring and even rigged applications. Whether you're powering your band’s live performance, DJ-ing a party, or MC-ing an event, be prepared for DBR Series speakers to take your performance to the next level.

Product Features

• FIR-X tuning delivers excellent sound quality with high resolution and a smooth frequency response
• D-Contour optimizes the DBR10 for main speaker or floor monitor use
• Onboard mixer lets you select either a direct output or a mixed output
• Comprehensive inputs for mixer, musical instrument, or media players
• Amplifier and power supply design provides powerful output from a compact speaker
• DSP-controlled protection functionality promotes optimum reliability

Attributes

• Total Power: 500W and Up

Technical Specifications

• Type: Loudspeaker
• Features: Powered
• # of Channels: 2
• Wattage: 700W
• Dimensions: 19.4" H x 12.1" W x 11.4" D
• Weight: 23.2 lbs
• Inputs: 2 x XLR/TRS Combo, 1 x Stereo
• Outputs: 1 x XLR
• Power Source: Standard IEC AC cable
• Maximum Peak SPL: 129dB
• Frequency Response: 55Hz-20kHz (-10dB)
• Driver Size: Under 30mm
• Horizontal Coverage Angle: 90 degrees
• Vertical Coverage Angle: 60 degrees
• Powered/Passive: Powered
