Designed for skillful showcasing and creative mixing, the PERFORMER is a 4-channel motorized DJ controller featuring RANE’s industrial build quality and legacy sound. High-torque motorized platters, enhanced stems control abilities, a MAG FOUR crossfader, and 4 PRECISION FEEL volume faders make this controller an exceptional choice for performance-focused professionals.

CREATIVITY IN MOTION

The PERFORMER boasts 7” high torque die-cast aluminum platters with acrylic discs that respond just like vinyl. Magnetically attached to the platters, the discs provide consistently accurate feedback. In the center of each platter is a high-definition 3.5” LCD screen that displays deck info, moving waveforms, album artwork, and library views. The Day Mode option reverses contrast for a clear view so nothing gets washed out when in sunlight.

PRECISION FEEL FADERS

In addition to the adjustable MAG FOUR crossfader, the PERFORMER mixer section features 4 revisited PRECISION FEEL FADERS. These adjustable tension faders utilize the same dual rail mechanical system of the MAG FOUR, but in a horizontal fader that’s mounted vertically on the circuit board. This translates into ultra-smooth, reliable, and consistent response when playing. The faders can be further customized in the onboard menu, giving you the ability to reverse them and adjust the cut-in curve from 0-100%.

STEMS CONTROL

With 4 unique options for controlling stems, the PERFORMER sets the standard for creative open format DJing. The PERFORMER features RANE’s exclusive STEM SPLIT feature, which automatically splits the acapella and instrumental sections across 2 mixer channels, giving you the freedom to add FX to individual elements, adding your own touch on the fly. STEM LEVEL

transforms the 3 band EQ on each channel into adjustment knobs, allowing you to adjust, kill, or boost individual elements.

EXPANDED FX CAPABILITIES

Add flexibility and distinct flavor with more than 25 paddle-triggered, fully customizable MAIN FX and 4 knob-controlled CHANNEL FX. This robust FX suite boasts traditional classics like Reverb and Echo, along with some newcomers such as Scale Down, Recycler, and Riser. The entire fader FX suite from the RANE SEVENTY A-TRAK SIGNATURE EDITION mixer has been ported over to the PERFORMER. This allows PRECISION FEEL volume faders to be used as linear controls for roll, pitch, and ring modulation. Seamlessly switch between the built-in hardware FX and Serato’s software FX, providing plenty of options for whichever style you choose.

RANE LEGACY

The RANE PERFORMER is the only 4-channel motorized DJ controller built to RANE’s rigorous standards. The PERFORMER earns the namesake from the talented professional artists that put this controller to work, making good use of the PRECISION FEEL FADERS, MAG FOUR crossfader, and industry-leading sound quality.

Tech Specs

Digital Audio

Converters

Cirrus Logic, 24-bit PCM, 48 kHz

Digital Signal Processing

32-bit, Floating Point, Double precision

Connections

(2) XLR outputs (Main)

(2) 1/4” outputs (Booth)

(1) RCA stereo output pair (Main)

(2) XLR / 1/4” (6.35 mm) TRS inputs (Mic 1–2)

(2) RCA stereo input pairs (Deck 3-4)

(1) 1/4” (6.35 mm) TRS output (Headphones)

(1) 1/8” (3.5 mm) TRS output (Headphones)

(2) USB Type-B ports

(1) IEC power cable input

Audio Outputs

Main Outputs

(XLR)

Gain Trim

Maximum Output

THD+N (20 kHz BW @ 1 kHz)

Frequency Response

Off to 0 dB

8 Vrms

0.004%

Flat - 20-20kHz

Main Outputs

(RCA stereo pair)

Maximum Output

THD+N (20 kHz BW @ 1 kHz)

Frequency Response

4 Vrms

0.004%

Flat - 20-20kHz

Booth Outputs

(1/4”)

Gain Trim

Maximum Output

THD+N (20 kHz BW @ 1 kHz)

Frequency Response

Off to 0 dB

8 Vrms

0.004%

Flat - 20-20kHz

Headphone Outputs

(1/4”/6.35 mm and 1/8”/3.5 mm TRS)

Maximum Output

Output Power

Dynamic Range (A-weighted)

4 Vrms Voltage: (no load)

50 mW (50 ohms)

108 dB

Audio Inputs

Microphone 1/2

(Combo XLR/1/4” [6.35 mm] TRS)

Analog Gain

Maximum Input

Gain Trim

Tone Control

25 dB

110 mV

Off to +26 dB (unity at center)

2-band

Line/Phono Inputs 3/4

(RCA stereo pairs, switchable)

Line

Maximum Input

Gain Trim

Tone Control

THD+N (20 kHz BW @ 1 kHz

4 Vrms

Off to +12 dB

3-band, full-cut to +10 dB

0.004%

Phono (RIAA)

RIAA Curve

Gain (@ 1 kHz)

Maximum Input (@ 1 kHz)

Dynamic Range (A-weighted)

+/-0.25 dB

31.5 dB

106 mV

102 dB

Pads

(16) on/off multi-color back-lit pads (8 per deck, 9 modes each

Wheel Displays

(2) 3.5” Color LCDs

Pad & FX Displays

(9) 128 x 32 Monochrome OLEDs

Faders

(1) MAG FOUR tension-adjustable crossfader with contour

(4) Precision Feel Faders (channel faders)

Power

Connection: IEC

Voltage: 100–240 V, 50/60 Hz

Consumption: 150 W

General

Dimensions

(width x depth x height)

30.84” x 15.84 x 4.32”

78.33 x 40.23 x 10.97 cm

Weight

28.20 lbs.

12.79 kg

Specifications are subject to change without notice.
