PXL PRO is a pedal group controller with 8 groups of effect loops that can be programmed and stored. In the past, when we used effect pedal, we usually connected the pedals one by one, and then turned on the pedals one by one. Or turn off the pedal you want to use, so that once the number of pedals increased, the operation becomes cumbersome. Especially in live performances, the original smooth and pleasant music will be greatly reduced due to the wrong effect or the failure to switch the effect in time. When using, just select the previously edited sound combination, You can make your effect system work continuously and stably without too much operation. Even if you turn off the power, the previous settings will not disappear. It can store up to 16 combinations. Internal TRUE BYPASS design minimizes the loss of sound, and avoids the pollution of the guitar signal by some effects that use electronic switches to switch as much as possible. on the other hand, the PXL PRO effect controller also has high switching speed and low switching noise.

Product Features

• Total 8 LOOP channels, but can be used as dual independent 4-channel setting
• Built-in 4 triggers enable you to use them to switch the Amp channel or effects mode settings
• Four triggers can be set separately for trigger polarity, mode and action status (including the settings under BYPASS)
• Tuner interface
• Independent mute switch for keeping mute or tuning

Attributes

• Color: Black

Technical Specifications

• Dimensions: 2.09" H x 21.3" W x 2.68" D
• Weight: 3.7 lbs
• Inputs: 1 x 1/4" (Input), 8 x 1/4" (FX Return)
• Outputs: 1 x 1/4" (Output), 8 x 1/4" (FX Send)
• Power Source: 9V DC power supply (not included)
• Effects: Utility & Signal Router
• Processing Type: Analog
