Dragonfire True Texas Strat AlNiCo 5 Single Coil Middle Position Dedicated Pickup, Black Cover

Dragonfire True Texas Single Coil Strat Middle Position Dedicated Pickup, AlNiCo V Modern Texas Performance ~ Black 52mm Standard Strat Cover Style

Dragonfire True Texas Strat pickups offer big, blue, truly Texas tone. True Texas pickups deliver a modern wound sound that’s a bit hotter than many standard single coils. For some players, this is the preferred output to achieve that “just-right” tone and you’ll find that these pickups shine in all areas – from mid-range to high as well as bass, these single coils showcase strength and quality. Excellent in presenting a focused performance, these are recommended for Blues, Rock, Classic Rock, Country and a variety of Pop genres.

The AlNiCo 5 magnets in these pickups are highly charismatic and provide warm, smooth tone for a well-rounded and dynamic outcome. Beveled vintage style slug polepieces with a gentle edge slope add visual depth and subtle detail while staggered pole styling allows for balanced output along with maximum string response and set-up options.

These are dedicated position pickups for performance enhancement and differentiation. Each pickup is wound specifically for a position and the Middle position pickup is Reverse-Wound and Reverse-Polarity (RWRP). These pickups are not position interchangeable.

This listing includes a standard black 52mm Strat cover color/style. We have a large variety of different standard and solid cover style options available. Check our Reverb Store or contact us if you'd like more information regarding cover colors.

~~Product Highlights~~

*Dragonfire True Texas Single Coil Strat Pickup

*6 String Passive Strat Single Coil Replacement

*Beveled Top Slug Staggered Poles

*Featuring AlNiCo 5 Magnet Style & Modern Winding

*2 Conductor Wiring (2 Wire Pickup Design)

*Cloth Wrapped Stranded Style Lead Wire Type

*Position Dedicated Performance Differentiation

*Wax Potted for Squeal Reduction, Avoidance or Elimination

*Upgraded Fiber Baseplate

*Pickup Mounting Screws & Springs Included

~~Approximate Measurements~~

*Middle Output: Wound to ~6.4K

*52mm Standard String Spacing

*Pickup Length: 69mm (82mm including mounting flanges)

*Pickup Width: 18mm

*Pickup Depth: 18mm

*Mounting Screw Spacing: 76mm

~~Installation Information~~

These 2-wire pickups come with a colored hot and a black ground wire for easy installation (colors may vary from sample images provided). Due to the vast and varied nature of possible components and set-up styles, we do not provide specific information or diagrams for installation. You should be able to use basic information and general knowledge to successfully complete installation with your choice of diagram or instructions.

If you’d like to update your wiring, switching, controls or functionality to upgrade your system, check out our custom Wiring Harnesses.

Installation requires soldering and compatible system. We provide enough pickup lead wire to complete installation wiring in standard usage situations.

~~Purchase Notes~~

Please ask any questions prior to purchase. Allow and expect variation in color due to photo and monitor settings, perception, lighting, as well as natural product variance. Color descriptions indicate color of item, not material. Ask any questions regarding options, measurements, installation requirements, special requests, or anything else prior to purchase.

Detailed instructions for installation are not included. You should be able to use basic knowledge of wiring with the diagram or instructions of your choice. Take your time for installation; do not use power tools and do not over-tighten or apply too much pressure on components.
