Yamaha Revstar Standard, Chambered Maple And Mahogany Body, Carbon-Reinforced Neck And Body, 2 P90-Style Pickups, Sunset Burst, Gig Bag Included

Revstar Standard: THE NEW STANDARD

With two available pickup configurations, 5-way switching, and the Focus Switch passive boost, the new Revstar Standard is all about versatility.

CHAMBERED BODY WITH ACOUSTIC DESIGN

Revstar Standard guitars feature chambered bodies designed to sculpt tone and reduce weight, with carbon reinforcement in the neck to improve vibration transfer.

5-WAY SWITCHING

With the same 5-way switching as Revstar Professional, the subtle phase shift on positions 2 and 4 offers a fresh take on classic “in-between” sounds.

FOCUS SWITCH

The push/pull Tone control activates a passive boost with an effect similar to overwound pickups—darker highs, increased mids and lows, and an aggressive character. The RSS02T offers P90-style single-coils. All pickups are custom designed by Yamaha and use Alnico V magnets for powerful tone.

RSS02T

This Revstar Standard features P90-style single-coil pickups with 5-way switching and the Focus Switch boost, with a custom racing tailpiece.

• 4 Café Racer inspired finishes
• Chambered maple and mahogany body
• Carbon-reinforced 3-piece mahogany neck
• 2 P90-style pickups
• 5-Position pickup selector
• Passive Focus Switch
• Deluxe gig bag included

General Specifications

• Scale Length 24-3/4” (628.6mm)
• Body Materials Top: Maple / Back: Chambered Mahogany
• Body Finish Gloss Polyurethane
• Neck Materials 3-Piece Mahogany, Carbon Reinforcement
• Neck Finish Satin Polyurethane
• Fingerboard Materials Rosewood
• Fingerboard Radius 12" (304.8mm)
• Fret Wire Jumbo Stainless steel
• Number of Frets 22
• Neck Width @ 0 Fret / 12th Fret 41.9 / 52.0 mm
• Thickness @1st Fret / 12th Fret 21.0 / 23.9 mm
• Neck Pickup VP5n: P90 type Single coil / Alnico V
• Bridge Pickup VP5b: P90 type Single coil / Alnico V
• Controls Master Volume, Master Tone (Push-Pull "Focus Switch")
• Pickup Switch 5-Position Lever Switch
• Bridge Tune-O-Matic
• Tailpiece Racing Tailpiece
• Pickguard 3-Ply Cream
• Case Gig Bag
