The Surfliner’s sound is driven by the Guild Rocker Pickup Switching System, with master volume, tone control, and 3 rocker switches. Each rocker switch is assigned to a single pickup allowing players to dial in a total of 7 pickup combinations, every possible combination available from the three pickups. The LB-1 Bridge pickup is a recreation of vintage Guild Humbuckers from the 60’soffering a range of tones well-suited for a variety of playing styles and genres. The middle and neck pickups are matched set of Dearmond Aerosonicmiddle and neck single-coil pickups. These pickups feature Alnico V magnets and a shielded nickel cover.

Body Type -Solid Body

Body Wood - Poplar

Neck Material - Maple

Scale Length - 25 1/2" (648mm)

Neck Shape - C Shape

Nut Width - 1 11/16" (43mm)

Neck Thickness 1st Fret - 21mm

Neck Thickness 9th Fret - 23.5mm

Truss Rod - Dual Action

Truss Rod Wrench - 4mm Allen Key

Fingerboard Material - Maple

Fingerboard Radius - 10" (254mm)

Fingerboard Inlays - 5mm Dots - Black ABS

Fingerboard Inlay Location - 3, 5, 7, 9, 12 (x2), 15, 17, 19, 21

Frets Total - 23

Fret Type - Narrow Jumbo

FinishColor - Catalina Blue (CLB)

Bridge String Spacing - 2" (50mm)

Hardware Finish / Plating - Nickel Plated

Bridge - Tune-O-Matic

Tailpiece - Sting-Thru Ferrules

Nut Material - Composite

Tuning Machines - Guild Vintage Style Inline Nickel

Strap Buttons - Vintage Style

Pickguard - Surfliner HSS 3-Ply White/Black/White

Bridge Pickup - Guild LB-1 Bridge Pickup

Neck Pickup - DeArmond Aerosonic Single Coil Pickup Neck Nickel/Black

Pickup Switch - Bridge Pickup - ON/OFF, Middle Pickup - ON/OFF, Neck Pickup - ON/OFFControlsMaster Volume and Tone, 3 x Rocker ON/OFF Pickup Switches

Strings - D'Addario EXL110 - Nickel Wound Regular Light (.010" - .046")

Upper Bout Width - 11" (280mm)

Lower Bout Width - 13 5/8" (346mm)

Body Depth Upper Bout - 1 1/2" (38mm)

Body Depth Lower Bout - 1 1/2" (38mm)

Body Length - 18" (457mm)

Overall Length - 41" (1041mm)
