Serial Number: ILL144310 Weight: 7lb 13oz

The RSS20 features six finish options, a chambered body and carbon-reinforced neck, dual humbucking pickups, 5-way switching, and a passive Focus Switch, providing exceptional versatility.

FEATURES

• 6 Café racer inspired finishes
• Chambered maple and mahogany body
• Carbon-reinforced 3-piece mahogany neck
• 2 Alnico V humbucking pickups
• 5-Position pickup selector
• Passive Focus Switch
• Deluxe gig bag included

HIGHLIGHTS

CHAMBERED BODY WITH ACOUSTIC DESIGN

Revstar Standard guitars feature chambered bodies designed to sculpt tone and reduce weight, with carbon reinforcement in the neck to improve vibration transfer.

5-WAY SWITCHING

With the same 5-way switching as Revstar Professional, the subtle phase shift on positions 2 and 4 offers a fresh take on classic “in-between” sounds.

FOCUS SWITCH

The push/pull Tone control activates a passive boost with an effect similar to overwound pickups—darker highs, increased mids and lows, and an aggressive character.

CHOICE OF PICKUPS

RSS20 and RSS20L feature humbuckers, and RSS02T offers P90-style single-coils. All pickups are custom designed by Yamaha and use Alnico V magnets for powerful tone.

Specifications

Case: Gig Bag

String Gauge: Elixir Nanoweb Light / 0.010-0.046

Pickguard: 3-Ply Cream

Tuning Machines: Die-Cast

Tailpiece: Racing Tailpiece

String Spacing: 10.5 mm

Bridge: Tune-O-Matic

Pickup Switch: 5-Position Lever Switch

Controls: Master Volume, Master Tone (Push-Pull "Focus Switch")

Bridge Pickup: VP5b: P90-Type, Single Coil/Alnico V

Neck Pickup: VP5n: P90-Type, Single Coil/Alnico V

Thickness @1st Fret / 12th Fret: 21/23.9 mm

Neck Width @ 0 Fret / 12th Fret: 41.9/52 mm

Nut Materials: PPS

Number of Frets: 22

Fret Wire: Jumbo Stainless Steel

Fingerboard Radius: 12" (304.8 mm)

Fingerboard Materials: Rosewood

Neck Finish: Satin Polyurethane

Neck Materials: 3-Piece Mahogany, Carbon Reinforcement

Body Finish: Gloss Polyurethane

Body Materials: Top: Maple / Back: Chambered Mahogany

Scale Length: 24-3/4” (628.6 mm)

Construction: Set-In
