Samson AirLine Micro Camera Wireless Lavalier Mic System - Channel N4 (644.750 MHz) 2020-2023 - Silver

SAMPSON Airline Micro

Samson SWAM2SLM10 N4 Overview

The Samson AirLine Micro Camera Wireless System combines the latest in lithium-ion battery technology, with miniature RF stable components. The result is an ultra-compact wireless microphone system that eliminates the need for battery changes, while providing stable, RFI (Radio Frequency Interference) free audio signal.

The system includes the AR2 compact receiver, AR2 receiver dock and AL2 bodypack transmitter with the LM10 omnidirectional lavalier microphone. The transmitter and receiver both feature built-in lithium-ion rechargeable batteries that are capable of up to 6 hours of operation on a full charge.

USB power inputs are featured on both the receiver and transmitter, although the AR2 receiver may be charged on the dock. A stereo 1/8" (3.5mm) mini output will plug your AR2 receiver into the PA system.

AirLine Micro Camera Wireless System

Wireless UHF 600 MHz system with micro-size transmitter and AR2 receiver

Tone squelch and auto mute for clear operation

Includes a convenient system carry case

Includes AC adapter and charging cables

AL2 Transmitter

Beltpack transmitter and LM10 omnidirectional lavalier microphone

Lithium-ion rechargeable battery (7-8 hours of operation)

USB DC input for recharging

Single-button operation for power, mute and volume

Multi-color LED displaying RF, low battery and power

AR2 Receiver

Low-profile wireless receiver (2.36 x 1.67 x 0.51")

Lithium-ion rechargeable battery (5-6 hours of operation)

USB DC input for power and recharging

3.5mm balanced mic/line level output

AR2 Dock

Provides secure base for AR2 receiver during operation and/or recharging

USB DC input for power and recharging (cables included)

3.5mm balanced audio output

Key Features

• Frequency N4: 644.750 MHz
• Lithium-Ion Rechargeable Batteries
• AR2 Portable Receiver
• AL2 Bodypack Transmitter
• Lavalier Microphone
• Powered Up to 6 Hours
• USB DC Power Inputs
• 1/8" (3.5mm) Stereo Mini Output

In the Box

• Samson AirLine Micro Camera Wireless System
• AL2 Bodypack Transmitter
• Samson LM10 Omnidirectional Lavalier Microphone for Samson Wireless
• AR2 Receiver
• AR2 Dock
• Power Cables
• Hot Shoe Mount
• 3.5mm Camera Connector
• XLR Camera Connector
• System Carry Case
• AC Adapter
• Charging Cables
• Limited 2-Year Warranty

Samson SWAM2SLM10 N4 Specs

Frequency Range Frequency N4: 644.750 MHz

Dimensions Receiver: 2.36 x 1.67 x 0.51" (59 x 42.41 x 12.95 mm)

Packaging Info

Package Weight 1.7 lb

Box Dimensions (LxWxH) 9 x 5.6 x 3.5"
