Overview

Back in 1986 a new breed of hard rock player was on the rise. To meet the demands of the players and their increasingly ‘hot-rodded’ amplifiers we set out to develop a modern guitar speaker capable of handling much more power and overdrive. To achieve this we coupled our ‘H’ magnet (the closest in performance to Alnico) with a new cone and voice coil employing contemporary materials.

Our most revealing speaker the Vintage 30 features enormously detailed and complex overtones a warm low-end a famously rich vocal mid-range and a beautifully detailed top-end. Used singly to reveal the complexities in hand- wired boutique amps or in quartets for a wonderfully intricate vintage 3D crunch the Vintage 30 sound has been captured on thousands of recordings from a diverse range of notable players including Slash Steve Stevens and Peter Frampton.

Specifications

• Nominal Diameter: 12in/305mm
• Nominal Power Rating: 60W
• Rated Impedance: 16Ω
• Sensitivity: 100dB
• Frequency Range: 70-5000Hz
• Resonance Frequency, Fs: 75Hz
• DC Resistance, Re: 7.3Ω or 12.9Ω
• Voice Coil Diameter: 1.75in / 44mm
• Chassis Type: Pressed steel
• Magnet Type: Ceramic
• Magnet Weight: 50oz/1.42kg
• Voice Coil Material: Round copper
• Cut-out Diameter: 11.1in/283mm
• Diameter: 12.2in/309mm
• Magnet Structure Diameter: 6.1in/156mm
• Mounting Hole Dimensions: Ø 0.31in/7.9mm
• Mounting Hole PCD: 11.7in/297mm
• Number of Mounting Holes: 4
• Overall Depth: 5.3in/135mm
• Unit Weight: 10.4lb/4.7kg
