Overview


Features


  • 1400 W continuous program power capacity
  • 100 mm (4 in) copper voice coil
  • 45 - 1000 Hz response
  • 93 dB sensitivity
  • Double silicone spider with optimized compliance

Specifications


  • Nominal Diameter: 320 mm (12.0 in)
  • Nominal Impedance: 4 Ω
  • Nominal Power Handling: 700 W
  • Continuous Power Handling: 1400 W
  • Sensitivity (1W/1m): 93.0 dB
  • Frequency Range: 45 - 1000 Hz
  • Voice Coil Diameter: 100 mm (4.0 in)
  • Winding Material: Copper
  • Former Material: Glass Fibre
  • Winding Depth: 21.0 mm (0.83 in)
  • Magnetic Gap Depth: 11.0 mm (0.4 in)
  • Flux Density: 1.05 T
  • Overall Diameter: 319 mm (12.5 in)
  • Bolt Circle Diameter: 299 mm (11.8 in)
  • Baffle Cutout Diameter: 281.0 mm (11.1 in)
  • Depth: 118 mm (4.6 in)
  • Flange and Gasket Thickness: 13 mm (0.5 in)
  • Air Volume Occupied by Driver: 3.5 dm3 (0.12 ft3)
  • Net Weight: 8.8 kg (19.4 lb)
  • Shipping Weight: 9.7 kg (21.38 lb)
  • Shipping Box: 360x360x200 mm (14.17x14.17x7.87 in)
