The 16 XLR Female (NOT COMBO) to 2 DB25 patch bay is a simple unit that allows 16 XLR Female Mic inputs  on 2 DB25 connectors. This unit can be connected via DB25-DB25 to any product that supports DB25 Tascam/Fostex/Digidesign analog 8 ch standard pin out. The DB25 will match with standard DB25 to XLR or TRS breakout cables from many vendors. Mamba patch bays are of highest quality to match your high end pro audio gear. The parts, design and construction are carefully done to provide the best audio quality.

16 Ch XLR Female Inputs on 2 DB25 1RU Panel
*** 5 Years Warranty ***

  • 16 Female XLR input VIA 2 DB25  (NOT Combo - ideal for Mic only Inputs)
  • DB25 compliant to Tascam/Fostex/Digi industry standard analog pin out
  • Compact 1U rack mount chassis & solid steel
  • Neutrik XLR quality and durable connectors
  • Modular approach with multiple input & output options
  • High quality DB25 connectors
  • Only 2" depth. 1RU.
  • Enclosed box to shield any outside interference. Solid steel and sleek finish
  • All connectors are mounted on PCB
  • All connections are routed on board (No wires inside)
  • No interference and clean analog pass thru

  • *** 5 Years of Warranty *****

    This item is sold As-Described

    This item is sold As-Described and cannot be returned unless it arrives in a condition different from how it was described or photographed. Items must be returned in original, as-shipped condition with all original packaging.Learn More.

    Promoted similar listings













    ConditionBrand New (New)
    Brand New items are sold by an authorized dealer or original builder and include all original packaging.Learn more
    Brand
    Model
    • 16XLRFDB25
    Finish
    • Black
    Categories
    Year
    • 2017
    Made In
    • United States
