Naiant PFA inline phantom power adaptor for stereo plug-in power microphone
This seller is currently away
See similar gear from other Reverb sellers
The PFA phantom power adaptor cable allows low-voltage microphones to connect to standard phantom-powered microphone inputs.
The PFA is available in a wide range of input connectors. This listing is for the stereo plug-in power microphone format, with a 3.5mm minijack input and 25cm cable.
Please note this item is now supplied with nickel connector shells instead of the black shells shown in the photo.
- Stereo plug-in power (“PIP”): tip = left + power (+8V across 6.8kΩ); ring = right + power (+8V across 6.8kΩ); sleeve = ground.
PFA phantom power adaptor cable specifications:
Phantom Power: +9-52V
Voltage Supplied to Microphones: low-voltage; +8V
Current, low-voltage microphone, electrically-balanced output, per channel: 2mA typical
Input Impedance: 6kΩ or as specified
Output Impedance: 150Ω
Recommended Preamp Input Impedance: 1.5kΩ or higher
Maximum Input Level, 1kHz @ 1% THD: +6dBV
Total Harmonic Distortion, 1kHz @ 0dBV: less than 0.005%
Frequency Response: 20Hz to 40kHz
Equivalent Input Noise: -121dBV unweighted, -124dBA
Weight (typical): 83g (2.9oz)
Dimensions (XLR): 70mm x 19mmø (2 3/4″ x 3/4″ø)
Dimensions (minijack): 35mm x 9mmø (1 3/8″ x 3/8″ø)
| Condition | Brand New (New) Brand New items are sold by an authorized dealer or original builder and include all original packaging.Learn more |
| Brand | |
| Model |
|
| Finish |
|
| Categories | |
| Made In |
|
Product safety information may be available here.
