The StudioLive 32SX Series III is a Compact 32-Channel Digital Mixer from PreSonus. The StudioLive 32SX Series III is available for purchase at the Music Store in Clermont Florida. This product is also available on our website. The Most Formidable StudioLive Yet

The StudioLive 32SX packs a lot of power for a compact console — it’s PreSonus’s most formidable offering yet. This 32-channel digital mixer boasts a dual-core FLEX DSP engine with enough muscle to drive 286 simultaneous processors, and then some. What’s more, its FLEX FX multi-effects processor vaunts four slots of reverb emulations and delays with four dedicated effects buses. Benefit from easy expandability thanks to built-in AVB networking. Enjoy versatile operation by virtue of the 32SX’s 16 FLEX Mixes. Shape and polish each channel to perfection courtesy of PreSonus’ lauded Fat Channel processing. The PreSonus StudioLive 32SX includes a comprehensive software suite, which enables you to make top-flight recordings right from the get-go.

Tech Specs

• Type:Digital Mixer
• Channels:32 channels, 40 mix channels
• Inputs - Mic Preamps:16 x XLR (mic), 16 x XLR-1/4" combo (mic/line)
• Phantom Power:Switchable per channel
• Inputs - Line:1 x Dual RCA Stereo (tape), 4 x 1/4" (2 x stereo aux in)
• Outputs - Main:2 x XLR (main out), 1 x XLR (mono sum), 2 x 1/4" (monitor)
• Outputs - Other:12 x XLR (mix out), 4 x 1/4" (mix out), 1 x Dual RCA Stereo (tape), 4 x 1/4" (sub outs)
• Outputs - Digital:1 x XLR (AES/EBU)
• Busses/Groups:16 x FlexMix Buses (aux, subgroup, matrix), 26 total mix buses
• Talkback:1 x XLR (phantom power)
• Data I/O:1 x Locking Ethernet (AVB audio network), 1 x RJ45 (network control)
• USB:1 x Type B (64 x 64)
• Computer Connectivity:USB 2.0
• Headphones:1 x 1/4"
• Faders:25 x Touch-sensitive motorized faders
• A/D Resolution:24-bit/48kHz
• Effects:FLEX FX Multi-effects processor, 4 x effects slots, 4 x effects buses
• Signal Processing:Fat Channel plug-ins, 10 x EQs, 10 x Compressors
• Transport Controls:Yes
• DAW Control:Advanced Studio One, MCU Logic emulation, HUI Pro Tools emulation
• Screen:7" Touchscreen
• Storage:SD card recorder (34 track)
• Software:Studio One Artist, UC Surface (Mac, Windows, Android, iPad), QMix-UC App (iOS, Android), Presonus Capture
• Power Source:Standard IEC AC cable
• Height:6.51"
• Depth:22.97"
• Width:25.98"
• Weight:30 lbs.
• Manufacturer Part Number:STUDIOLIVE 32SX
