Loud and clear, the ELX200-12 delivers an accurate, linear response at any volume for any venue. The ELX200-12 is one of the strongest full-range composite enclosures ever built by EV. The ELX200 series supplies maximum efficiency with maximum toughness.

Electro Voice ELX200-12 12" 2-Way Full Range Passive Loudspeaker Features

• 1200 W (peak), 128 dB peak SPL system that is reliability verified with over 500 hours of abuse testing and endurance testing to 4x typical industry practices.
• 1.4 inch DH-1C (1 inch exit) titanium compression driver for extended transparent high-frequency response.
• High-output EVS-12M woofer designed to exacting specifications for superior durability and exceptional low-frequency reproduction.
• EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage, minimal distortion, and maximized acoustical loading.
• Professional-grade hardware: three M10 threaded mounting points for forged eyebolts, integrated pole-mounts and the proven ZLX three-handle design for easy lifting.

The ELX series is designed to deliver an unprecedented combination of sound quality, portability and durability at its price point. All-new custom components—tested to levels far exceeding the industry norm—make ELX200 a robust workhorse capable of handling real-world abuse and professional applications beyond the capability of competitors’ products in its category.

Every aspect of ELX200 is designed for ideal results as part of the whole - the acoustical, electrical and mechanical components all work together seamlessly. The full-range models feature a low profile form factor designed with a high-spec composite enclosure to balance weight, manageability, as well as structural integrity. The proprietary features that have made the other members of the EV portable speaker family a goto for best-in-class performance are also present: Signal Synchronized Transducers (SST) waveguide concept.

EV's industry-leading quality and testing procedures yield efficient transducer design and meaningful specs, resulting in components that deliver new benchmark for toughness - both acoustically and physically

CALIFORNIA PROPOSITION 65 WARNING
WARNING: Cancer and Reproductive Harm -

Electro Voice ELX200-12 Passive Loudspeaker Specifications

• Coverage (Nominal -6 dB) H: 90°
• Coverage (Nominal -6 dB) V: 60°
• Crossover Frequency: 1.7 kHz
• Depth: 344 mm (13.54")
• Enclosure Material: Polypropylene composite
• Family: ELX200
• Frequency Range (-10 dB): 51 Hz - 20 kHz
• Frequency Response (-3 dB): 77 Hz - 17 kHz
• Grille:18 AWG steel with powdercoat
• Height: 629 mm (24.76")
• HF Transducer: DH-1C 1-inch titanium compression driver
• LF Transducer: EVS-12M 300 (12 in)
• Max. SPL/1m (calc) : 128 dB
• Minimum Impedance: 7.5Ω
• Nominal Impedance: 8Ω
• Power Handling (Continuous / Peak): 300W/1200W
• Power Rating: 1200W
• Recommended High-Pass Frequency: 50 Hz
• Shipping Weight: 17.1 kg (37.7 lbs)
• Speaker Type: Full-Range
• Suspension: (3) M10 suspension points
• Weight Net: 15.2 kg (33.51 lbs)
• Width: 363 mm (14.29")
• Woofer Size: 12 inch
