Durability in a super lightweight enclosure, the ELX200-12S subwoofer packs a powerful low-frequency output into a surprisingly compact footprint. Featuring a tuned 15 mm thick wood enclosure with a premium top-coat finish, the ELX200-12S subwoofer is the best-in-class for performance.

Electro Voice ELX200-12S 12" Passive Subwoofer Features

• 1600 W (peak), 129 dB peak SPL utilizing high sensitivity transducer designed and engineered by EV for maximum punch.
• High-output EVS-12L woofer designed to exacting specifications for superior durability and exceptional low-frequency reproduction.
• System reliability verified with over 500 hours of abuse testing and endurance testing.
• Ideal for portable and installed applications. Lightweight, compact 15 mm wood enclosure with internal bracing with durable polyurea top-coat finish.
• Professional-grade hardware: integrated M20 threaded pole mount plate and two-handle design for easy lifting.

The ELX series is designed to deliver an unprecedented combination of sound quality, portability and durability at its price point. All-new custom components—tested to levels far exceeding the industry norm—make ELX200 a robust workhorse capable of handling real-world abuse and professional applications beyond the capability of competitors’ products in its category.

Every aspect of ELX200 is designed for ideal results as part of the whole - the acoustical, electrical and mechanical components all work together seamlessly. The subwoofers pack powerful low-frequency output into a surprisingly compact footprint, and feature tuned 15 mm thick wood enclosures with a premium top-coat finish. The proprietary features that have made the other members of the EV portable speaker family a go-to for best-in-class performance are also present.

EV's industry-leading quality and testing procedures yield efficient transducer design and meaningful specs, resulting in components that deliver accurate, linear response at the system’s highest output levels. Translation: loud and clear all the way up to the limit. Unified in one of the strongest full-range composite enclosures ever built by EV. The ELX200 is established as the new benchmark for toughness - both acoustically and physically; maximum efficiency with maximum toughness.

CALIFORNIA PROPOSITION 65 WARNING
WARNING: Cancer and Reproductive Harm -

Electro Voice ELX200-12S 12" Passive Subwoofer Specifications

• Depth: 457 mm (17.99")
• Enclosure Material: 15 mm plywood with durable polyurea top-coat finish
• Family: ELX200
• Frequency Range (-10 dB): 33 Hz - 300 Hz
• Frequency Response (-3 dB): 42 Hz - 220 Hz
• Grille: 18 AWG steel with powdercoat
• Height: 397 mm (15.63")
• LF Transducer: EVS-12L 300 mm (12 in)
• Max. SPL/1m (calc): 129 dB
• Minimum Impedance: 6.9Ω
• Nominal Impedance: 8 ΩΩ
• Power Handling (Continuous / Peak): 400 W/1600W
• Power Rating: 1600W
• Recommended High-Pass Frequency: 42 Hz
• Shipping Weight: 20.2 kg (44.53 lbs)
• Speaker Type: Subwoofer
• Weight Net: 20.2 kg (44.53 lbs)
• Width: 445 mm (17.52")
• Woofer Size: 12 inch
