Ahead of its time when it debuted in 1982, the VB-2 Vibrato has been rediscovered by modern players looking to create unique guitar textures with stompbox effects. Thanks to its expressive, one-of-a-kind sound, this rare pedal has gone on to become one of the most valuable BOSS effects in the vintage market. Now, the progressive spirit of the VB-2 has been reborn as the Waza Craft VB-2W. Using all-analog circuitry, the VB-2W authentically reproduces the true pitch-shifted vibrato of the original pedal, and also adds an innovative new vibrato mode and real-time control function for enhanced expression.

FEATURES

• Premium edition Waza Craft pedal delivers the ultimate BOSS tone experience
• Custom mode features a totally new vibrato sound with unique filter wave
• Standard mode provides a true reproduction of the vintage VB-2 Vibrato sound
• All-analog circuit with BBD (bucket brigade) vibrato line
• Control the effect depth in real time with an optional expression pedal
• Rise Time knob to control the initial onset of the vibrato effect
• Unlatch mode activates the effect only while pressing the pedal, ideal for adding vibrato to specific notes and chords
• Bypass mode takes the BBD out of the signal path to eliminate latency when the effect is off
• BOSS five-year warranty

SPECIFICATIONS

• Modes (3): LATCH, UNLATCH, BYPASS
• Nominal Input Level: -20 dBu
• Input Impedance: 1 M ohm
• Nominal Output Level: -20 dBu
• Recommended Load Impedance: 10 k ohms or greater
• Bypass: Buffered Bypass
• Controls: Pedal switch
  Standard/Custom switch
  RATE knob
  DEPTH knob
  RISE TIME knob
  MODE knob
• Connectors: INPUT jack
  OUTPUT jack
  DEPTH jack
  DC IN jack
• Power Supply: Alkaline battery (9V, 6LR61) or Carbon-zinc battery (9V, 6F22)
  AC adaptor (sold separately)
