Screamers HH Set, Humbucker Bridge + Humbucker Neck Pickup, Passive, Hot, MATTE Black

Dragonfire Screamers ~ Brand New Hot Humbucker Pickups ~ Passive Humbucker Pickup Set, Bridge & Neck HH Set ~ Hot Humbucking for Great All-Around Performance ~ Ceramic Magnet Style, Humbucker Set: 1 Bridge Pickup + 1 Neck Pickup

Dragonfire Screamers are the ultimate humbucker for high output and clarity. These are hot wound and use ceramic magnets, providing a crisp, clean, and modern tone that’s great for all-around performance. They produce a staggering 16.9K (approximate) output on the bridge and 8.3K (approximate) output on the neck to help your playing come to life. The Screamers provide you with the ability to cut through the mix and be heard. They’ll help give you output without the mud, allowing for power and articulation.

The Screamer pickup is a straightforward pickup with flat top style polepieces. This HH set is collaborative and the pickups work together for the best possible performance. Check our Reverb Store if you only need one - we have these available separately as individual bridge or neck pickups. We also offer this same pickup style in other colors so you can personalize your set-up. Please see our Reverb Store page and contact us if you have any questions or would like more information.

These humbuckers are 4-wire so you can coil-split for even more versatility. In single coil mode, this humbucker functions well and performs with smooth clarity. We recommend using 500K pots and 0.047 tone caps (available separately).

~~Product Highlights~~
*Brand New Passive Pickups ~ Collaborative Bridge & Neck Position Use
*6-String Standard Guitar Pickups ~ Ceramic Magnet Style
*Hot Wound 4 Conductor Wiring (4 Wire Pickups)
*Coil Split Capable (sometimes referred to as Coil Tap)
*52/50 Spacing (Standard F-Spacing)
*Wax Potted for Squeal Reduction or Elimination
*Short Style Mounting Legs (Standard Style)
*Flat Top, Slug Style Exposed Polepieces
*Uncovered Open Coil Bobbin Style
*Standard Insulated Lead Wire (Stranded Style)
*Pickup Mounting Screws & Springs Included

~~Approximate Measurements~~
*Polepiece Spacing: 52mm (Bridge) & 50mm (Neck)
*Approximate Output: ~16.9K (Bridge) & ~8.3K (Neck)
*Pickup Length: 68mm (84mm including mounting flanges)
*Pickup Width: 37mm
*Pickup Depth: 22mm
*Mounting Screw Spacing: 78mm

~~Installation~~
Basic wire color codes are included and will let you know which wires are hot and which are grounds. Due to the vast and varied nature of possible set-ups, we do not provide specific information or diagrams for installation. You should be able to use the simple information we provide to match up with any diagram or instructions you choose to use. Sample wiring instructions for a standard build are included for your reference. Installation requires soldering and compatible system. We provide enough pickup lead wire to complete installation in standard usage situations. Take your time for installation; do not use power tools and do not over-tighten or apply too much pressure on components.

~~Purchase Notes~~
Ask any questions prior to purchase. Buyers assume all risk of use; sales are only offered to those competent to safely and lawfully purchase and use items.

Allow and expect variation in color due to photo and monitor settings, perception, lighting, as well as natural product variance. Color descriptions indicate color of item, not material. Ask any questions regarding options, measurements, installation requirements, special requests, etc. prior to purchase.

Inspect your order upon receipt. We will address any issues PRIOR to installation. If everything is in order, simply install carefully to enjoy.
