GAR AM-10 (Quad Eight Type) Discrete OpAmp (API 2520 Pinout)

Brand new GAR AM-10 op-amp, hand built at our studio in Chicago. Soldering is tight and neat and the PCBs are fully cleaned. Op-amps are burned in and tested with a scope and spectrum analyzer.  We also make and have listings for other op-amps such as GAR 2520, CA-0252, and 990 types.

The AM10 is a modern design by Gary Barnett of the vintage Quad Eight AM10 discrete op-amp in the API 2520 pinout format. You can use this to replace API 2520 op-amps that are dead or as an upgrade.

Description from CAPI:

This DOA is a ten transistor amplifier modeled after the legendary Quad-Eight AM10. Gary has reformatted the layout to match the 2520 footprint. The original AM10 layout was a completely different proprietary footprint.

It should be noted that the garAM10 has been rigorously tested on +/-28 V rails with great success. The original AM10 was actually designed to run on +/-28 V rails. So as a bonus, the garAM10 can be used in the GDIY 51x format which utilizes +/-24 V rails.

Some of the applications the garAM10 DOA can be used for:
- Microphone Preamplifiers
- Line or Booster Amplifiers
- Lossless Combining Amplifiers
- Balanced Transformerless Amplifiers
- Equalizers and Compressors

Additional features and specs:
- Industry standard 2520 footprint for plug-in or PC mount connections
- Low noise, high power output
- Low distortion
- Minimum load impedance is 75 ohms for full output voltage
- Power supply voltage is bi-polar +/- 12 VDC to +/- 28 VDC
