The Sound Town CARPO-L1 is a portable all-in-one PA speaker system that you can carry around from gig to gig. With a customized 8“ powered subwoofer and a column speaker with four 2.5” full-range drivers, it delivers rich bass and crisp highs. All drivers are positioned at precise angles and the the speaker provides great sound coverage. There are also two height spacers included that allows you to adjust the height of the array speaker. It is a professional-quality portable PA system for a great-sounding show.
The CARPO-L1 has a built-in 3-channel mixer and comes with two 1/4“ and XLR inputs (MIC/Line switchable), one 3.5mm Aux in and Mix-out, enabling you to connect your guitar and portable media player directly; Built-in MP3 module support USB/SD inputs. The speaker is equipped with Bluetooth 5.0 and so you can stream music from your Bluetooth enabled devices. The True Wireless Stereo (TWS) function allows you to pair two CARPO-L1 speakers at the same time for even more powerful real stereo sound.
The Sound Town CARPO-L1 is compact and light enough to carry around and can be set up in seconds. Better yet, with a carry bag for the spacers and column speaker, the whole PA system can be easily transported from gig to gig. It is ideal for live performance, speech, movie night and venues such as home, coffee house, auditorium and etc.
Important! The USB port on this product is designed ONLY for connecting a flash drive to play music. DO NOT attempt to use it to charge any device, as it may cause damage to the amplifier.
CARPO SERIES
The Sound Town CARPO series PA speakers and subwoofers feature high-quality transducers inside and sleek enclosure design outside. They provide industry-leading performance and reliability that cannot be beat at their prices. Without compromising sound quality, The CARPO series builds compact and portable PA speaker systems that are perfect for live sound performance or installation applications. It is ideal for professional musicians and venues such as clubs, bars, restaurants, churches and schools etc.
FEATURES
-
TWS BLUETOOTH EQUIPPED: The speaker is equipped with Bluetooth 5.0 and so you can stream music from your Bluetooth enabled devices. The True Wireless Stereo (TWS) function allows you to pair two CARPO-L1 speakers at the same time for even more powerful real stereo sound.
-
BUILT-IN MIXER FOR GREAT FLEXIBILITY AND CONTROL: The CARPO-L1 has a built-in 3-channel mixer and comes with two 1/4“ and XLR inputs (MIC/Line switchable), one 3.5mm Aux in and Mix-out respectively, enabling you to connect your guitar and portable media player directly; Built-in MP3 module support USB/SD inputs as well.
Important! The USB port on this product is designed ONLY for connecting a flash drive to play music. DO NOT attempt to use it to charge any device, as it may cause damage to the amplifier.
-
VERSATILE APPLICATIONS: With an all-in-one mixer, versatile input and output connectors, top-quality woofer and full-ranger drivers positioned at optimized angles, the Sound Town CARPO-L1 array speaker PA system is ideal for live performance, speech, movie night and venues such as home, coffee house, auditorium and etc.
-
PREMIUM SOUND AND GREAT COVERAGE: With one 8“ powered subwoofer and a column array speaker with four 2.5” full-ranger drivers, the CARPO-L1 delivers rich bass and crisp highs; All drivers are positioned at precise angles and the the speaker system provides great sound coverage. There are also two height spacers included that allows you to adjust the height of the array speaker. It is a professional-quality portable PA system for a great-sounding show
-
LIGHTWEIGHT AND EASY TO SET UP: The Sound Town CARPO-L1 is compact and light enough to carry around and can be set up in seconds. Better yet, with a carry bag for the spacers and column speaker, the whole PA system can be easily transported from gig to gig
SPECIFICATIONS
Specifications
Model
CARPO-L1
Active / Passive
Active
Frequency Range
40 Hz - 20 kHz
Frequency Response
45 Hz - 20 kHz
Sensitivity
120 dB
SPL Max
143 dB
Dispersion
120º x 60º (H x V)
Configuration
Portable line array column speaker with powered subwoofer PA system
Transducer
LF: 1 x 8" woofer, HF: 4 x 2.5" full-range
Voice Coil
2" VC
Magnet
30 oz
Impedance
Subwoofer: 2Ω, Column Array Speaker: 4Ω
Power Handling
200W RMS / 400W peak
Cabinet Construction
ABS
Mounting
2 spacers (included)
Finish
Textured plastic
Grill & Rigging Component
Steel with anti-corrosion coat
Amplifier
Class-D
Input
2 x XLR, 2 x 1/4" (line/mic input), 1/8" AUX, MP3, TWS Bluetooth
Output
XLR (mix line out)
Control
Effect, bass boost, level, master volume
Indicator
Power, limit
Voltage
100V-240V (50-60 Hz)
Dimension & Weight
Product Width (in.)
13"
Package Width (in.)
19.7"
Product Height (in.)
73.6" (w/ spacers)
Package Height (in.)
23.6"
Product Depth (in.)
13.8"
Package Depth (in.)
18.1"
Product Weight (lb.)
32.0 lbs
Package Weight (lb.)
37.6 lbs
Warranty/Certifications
Manufacturer Warranty
1 Year
