2x B&C 18DS100-4 18" Professional Neodymium Subwoofer 4" Voice Coil 3000W 4 Ohm

B&C 18DS100-4 18" Professional Neodymium Subwoofer 4" Voice Coil 3000W 4 Ohm

This next evolution subwoofer uses a new, longer, four layer aluminum voice coil. The result is less heat, more energy in the gap, higher sensitivity, higher power handling, lower distortion and better overall performance. The 18DS100 features a 36mm long, 4 inch diameter (100mm) Copper Clad Aluminum Wire voice coil. With a 1500 watt AES power rating, 98 dB sensitivity, and over 14.0mm of Xvar, this high energy subwoofer is a significant step forward from similar models in the B&C range.

Product Specifications

• Nominal Diameter 18"
• Power Handling (RMS) 1,500 Watts
• Power Handling (max) 3,000 Watts
• Impedance 4 ohms
• Frequency Response 32 to 1,000 Hz
• Sensitivity 98 dB 2.83V/1m
• Voice Coil Diameter 4.0"

Thiele-Small Parameters

• Resonant Frequency (Fs) 32 Hz
• DC Resistance (Re) 2.5 ohms
• Voice Coil Inductance (Le) 2.82 mH
• Mechanical Q (Qms) 10.0
• Electromagnetic Q (Qes) 0.24
• Total Q (Qts) 0.24
• Compliance Equivalent Volume (Vas) 5.54 ft.³
• BL Product (BL) 24.3 Tm
• Diaphragm Mass Inc. Airload (Mms) 300.0g
• Maximum Linear Excursion (Xmax) 13 mm
• Surface Area of Cone (Sd) 1,210.0 cm²

Materials of Construction

• Cone Material Treated Paper
• Surround Material Cloth
• Voice Coil Wire MaterialCopper
• Voice Coil Former Aluminum
• Basket / Frame MaterialCast Aluminum
• Magnet Material Neodymium

Mounting Information

• Overall Outside Diameter 18.11"
• Baffle Cutout Diameter16.61"
• Depth 9.41"
• Bolt Circle Diameter 17.44"
• # Mounting Holes 8

Optimum Cabinet Size

• Sealed Volume 0.5 ft.³
• Sealed F3 117 Hz
• Vented Volume 2.5 ft.³
• Vented F3 62 Hz
