The OD-1X launches the famous BOSS overdrive into a modern era of expression, delivering an unmatched level of performance for guitarists with an ear for tone. This next-generation stomp combines over 35 years of innovation in pedal design with the most advanced technologies, bringing you a completely new tonal experience that’s only possible with the legendary expertise of BOSS. Prepare to be amazed—the inspiring and ultra-responsive OD-1X will change your thinking about overdrive pedals forever.
Nominal Input Level-20 dBu Input Impedance1 M ohm Nominal Output Level-20 dBu Output Impedance1 k ohm Recommended Load Impedance10 k ohms or greater ControlsPedal switch
LEVEL knob
LOW knob
HIGH knob
DRIVE knob IndicatorCHECK indicator (Serves also as battery check indicator) ConnectorsINPUT jack
OUTPUT jack
AC adaptor jack (DC 9 V) Power SupplyAlkaline battery (9V, 6LR61) or Carbon-zinc battery (9V, 6F22)
AC adaptor (sold separately) Current Draw45 mA Expected battery life under continuous useAlkaline: Approx. 9 hours
Carbon: Approx. 2.5 hours

* These figures will vary depending on the actual conditions of use. AccessoriesOwner's Manual
Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTE," and "Information")
Alkaline battery (9V, 6LR61) Option (sold separately)AC adaptor (PSA series) SIZE AND WEIGHTWidth73 mm
2-7/8 inches Depth129 mm
5-1/8 inches Height59 mm
2-3/8 inches Weight450 g
1 lbs.
