Brand new - Closed Box
We are Millennia Media distributors, among 100 other excellent brands.

Note: For specific shipping rates outside Europe please message us before buying.

Note 2: We sell without taxes anywhere outside Europe and to valid VAT ID companies inside Europe. Please ask us your price without Tax in those cases.

Note 3: This product is sent factory direct. Please allow 10 to 15 days for shipping.

Authentic Transparency for Unrestricted Creativity

• Unsurpassed ambience retrieval
• Transformerless design with matched hi-speed discrete transistor octet has +23 dBu input headroom: no attenuator “pads” needed
• Uncolored timbral accuracy at all dynamic levels
• Entirely balanced audio path with precision components maintains signal integrity: THD under 5 ppm (.0005%)
• Effortless, vividly realistic musical performance
• Laser-trimmed FET-based output stage has 32 dBu headroom: drives 1000 foot (300 m) cable runs with ease
• Standard 36-step gain controls (1.5 dB per step) are stereo matched to .08 dB
• Ultra-clean universal power supply
• Gold switches
• Mogami Neglex OFC audio wiring
• Silver Teflon power wiring
• Welded 16 gauge steel rack chassis

Options:

• Ribbon optimized DC coupled input - $100/channel
• Extra 10dB gain - no charge
• DPA 130V input  - $300/channel
• Dante, AES or MADI digital outputs

Specifications

Minimum Gain 8.5 dB

Maximum Gain (1.5 dB per step, 36 steps) 65 dB (up to 75 dB on request)

Frequency Response (+0 / -3 dB) sub 3 Hz to beyond 300 kHz

Noise (60 dB Gain, 10 Hz - 30 kHz, Inputs common) -133 dB EIN

Total Harmonic Distortion + Noise (35 dB Gain, 10 Hz - 20 kHz bandwidth, +27 dBu Out) < .001%, Typ. < .0005% (< 5 ppm)

Intermodulation Distortion (50 Hz & 7 kHz) 35 dB Gain, +27 dBu Out < .0009%

Phase Response (35 dB Gain, 50 Hz - 20 kHz bandwidth, +27 dBu Out) < 2 degrees deviation

Common Mode Rejection Ratio (35 dB Gain, 10 Hz - 20 kHz bandwidth, 100 mV C.M.) > 65 dB, Typ > 85 dB

Slew Rate (35 dB Gain, +27 dBu Out) > 25 Volts per microsecond

Maximum Input Level (20 Hz - 40 kHz) +23 dBu (no attenuator pads required)

Maximum Output Level (20 Hz - 40 kHz) +32 dBu

Phantom Input Impedance (1 kHz) 6,750 ohms

Output Impedance 24.3 Ohms (x2)

DPA (B&K) Mic Powering +130 V dc max, (non-phantom)

Phantom Powering +48 V dc, +/- 4 V dc

Power Consumption 45 watts maximum

Power Requirements 100V to 240V, 50/60 Hz

Dimensions/Shipping Weight 19” W x 3.5” H x 12.5” D, 21 lbs.
