Authentic Transparency for Unrestricted Creativity

• Continuously variable gain control
•  Front panel instrument input
• DC coupled ribbon mic with 10dB gain boost setting
• 80 Hz rolloff filter
• 48V phantom power
• 15 dB Pad
• Polarity flip

Specifications

Minimum Gain 14.5 dB, 1dB with Pad

Maximum Gain (continuously variable) 60 dB (70 dB in Ribbon Mode)

Frequency Response (-3 dB) < 10 Hz to > 200 kHz

typical -1.0 dB @ 10 Hz

typical -1.5 dB @ 200 kHz

Noise  (60 dB Gain, 10 Hz - 30 kHz, Inputs common) -130 dB EIN

Total Harmonic Distortion + Noise  (35 dB Gain, 10 Hz - 20 kHz bandwidth, +24 dBu Out) < .003%, Typical < .001%

Intermodulation Distortion (50 Hz & 7 kHz) 35 dB Gain < .0006% +12 dBu Out

< .001% +20 dBu Out

Phase Response (35 dB Gain, 50 Hz - 20 kHz bandwidth, +27 dBu Out) < 2 degrees deviation

Common Mode Rejection Ratio  (35 dB Gain, 10 Hz - 20 kHz bandwidth, 100 mV C.M.) > 65 dB, Typ > 85 dB

Slew Rate (35 dB Gain, +24 dBu Out) > 25 Volts per microsecond

Maximum Input Level (20 Hz - 40 kHz) +12dBu @ 0.02% THD+N

Maximum Output Level 1 kHz @ 35dB of gain, THD+N is:

< 0.001% at +26dBu output

< 0.05% @ +28 dBu output.

Phantom Input Impedance  (1 kHz) 2,210 ohms

Output Impedance 24.3 Ohms (x2)

Phantom Powering

  provided by 500 rack

Dimensions/Shipping Weight 1.5” W x 5.25” H x 6” D, 2 lbs.
