Heptode Jim '81 Rackmount 100W Guitar Amp Head

The Jim '81 amp offers very unique specifications, combining rich features, low weight, high reliability and awesome sounding.

Two legendary amps inside the Jim '81

• Two independant channels inspired by Fender* Blackface and Marshall JCM800* amps, adjustable output power up to 100W, an effect loop, a DI output with Cabinet Simulator, lightweight. These make the Jim '81 a totally unique guitar amplifier.

General

• 1U rackmount enclosure, only 2kg / 4.4lbs
• 2 channels
• Adjustable output power from 0 up to 100W
• Effects loop
• DI output with speaker cabinet simulator
• Heptode proprietary analog technology
• High end Class D audio amplifier

Channels

• Leo: simulates a Fender* Blackface amp
• Jim: simulates a Marshall JCM800 2203* amp

Controls (Leo channel)

• Volume
• Bass, Middle, Treble
• Power level (0 to max power)

Controls (Jim Channel)

• Preamp Volume
• Master Volume
• Bass, Middle, Treble
• Presence
• Power level (0 to max power)

Other controls

• Leo/Jim channel switch
• Low/Full (15W/100W) max output power
• Cabsim on/off switch
• Ground lift switch for DI XLR output

Inputs/Ouputs

• 2 Guitar inputs (front/rear panels)
• 2 Speaker outputs (4Ω minimum)
• 1 Footswitch input (channel selection)
• 1 Send output / 1 Return input (effects loop, +4dBU)
• 1 Line Out ouput (Jack)
• 1 DI ouput (XLR)
• Mains input : 120V or 230V (factory setting, please specify), 50/60Hz

Output Power

• Max output power: 100W @ 4Ω; 50W @ 8Ω; 25W @ 16Ω

Dimension and weight

• 48 x 4.4 x 22 cm, 2.0 kg  - 18.9" x 1.6" x 8.7", 4.4 lbs

Heptode amps carry a 3 years limited warranty.
