The smallest ceramic guitar speaker in the Jensen range, the C6V has a smooth tone with rich midrange, excellent detail on the top end, and a convincing bass range for its size. The 20W power handling ensures good headroom, dynamics and articulation, even with mid and high gain tones.

Guitarist Description: Extremely versatile. Warm clean tone with top-end chime. It remains strong and articulate when presented with overdrive distortion.

• Lows: Tight
• Mids: Firm
• Highs: Smooth
• Overdrive: Crunchy

Product Measurements

Nominal Overall Diameter: 165.00 mm
Nominal Voice Coil Diameter: 25.00 mm
Magnet Weight: 245.00 g
Flux Density: 1.00 T
Voice Coil Winding Depth: 7.00 mm
Magnetic Gap Depth: 5.00 mm
Magnet Type: Ferrite
Voice Coil Winding Type: Copper
Voice Coil Former: Epotex
Cone Material: Paper
Surround Material: Integrated Paper
Dust Dome Material: Non-treated Cloth
Basket Material: Pressed Sheet Steel
Surround Treatment: Yes
Voice Coil DC Resistance (Re): 6.58 Ω
Resonance Frequency (ƒS): 106.30 Hz
Mechanical Q Factor (QMS): 10.65
Total Q Factor (QTS): 1.08
Mechanical Moving Mass (MMS): 6.80 g
Mechanical Compliance (CMS): 327.00 µm/N
Force Factor (BxL): 5.00 Wb/m
Equivalent Acoustic Volume (VAS): 7.00 liters
Linear Displacement, maximum (XMAX): 0.50 mm
Reference Efficiency (nO): 0.67 %
Diaphragm Area (SD): 122.70 cm2
Losses Electrical Resistance (RES): 58.40 Ω
Voice Coil Inductance @ 1 kHZ (LE): 0.48 mH
Rated Power: 20.00 W
Musical Power: 40.00 W
Sensitivity @ 1W, 1m: 91.30 dB
