Recommended for professional audio mid-range applications in a sealed cabinet, or as a mid-bass in a vented satellite enclosure.

Specification

  • Nominal Basket Diameter 6.5", 165mm
  • Nominal Impedance* 4 ohms
  • Power Rating**
  • Watts 100W
  • Music Program 200W
  • Resonance 107Hz
  • Usable Frequency Range 95Hz - 5.5kHz
  • Sensitivity*** 93.3dB
  • Magnet Weight 20 oz.
  • Gap Height 0.25", 6.35mm
  • Voice Coil Diameter 1.5", 38.1mm
  • Mounting Information
  • Recommended Enclosure Volume
  • Sealed 4-23 liters / 0.2-0.8 cu.ft.
  • Vented 6-11 liters / 0.2-0.4 cu.ft.
  • Driver Volume Displaced 25 cu.in. / 0.41 liters
  • Overall Diameter 6.59", 167.4mm
  • Baffle Hole Diameter 5.65", 143.5mm
  • Front Sealing Gasket Fitted as standard
  • Rear Sealing Gasket Fitted as standard
  • Mounting Holes Diameter 0.23", 5.8mm
  • Mounting Holes B.C.D. 6.06", 154mm
  • Depth 2.8", 71mm
  • Net Weight 4.1 lbs, 1.9 kg
