Barcus-Berry Planar Wave 4000XL Stereo Pair – SOUND DESIGNER KIT – Mint, Boxed

Barcus-Berry Planar Wave 4000XL Stereo Pair – 2 Pickups & 2 Preamps – Mint, Boxed
.
Hello + welcome to my small stall here on Reverb .. Im a hobbyist musician, sound designer and sound artist. I have had a few releases out + and Im always trying out new techniques for sound capturing.
My shop has a few items, but over the year will have 100s of small cool sound things - from my studio.
none of the kit has been performed out - or field recorded (unless stated). I will also supply you with the most accurate photos + information + I take packing seriously + I do it right ! (shipping globally no problem) .. So here is the fantastic "Stereo Pair or Sold as Mono - see my listings) ..
.
Barcus-Berry Planar Wave 4000XL Stereo Pair – 2 Pickups & 2 Preamps – Mint, Boxed .. what makes it special?
.
Small vibrations. Entire sound worlds.
A mint, boxed stereo pair: two Barcus-Berry Planar Wave contact pickups and two 4000XL piezo preamps. Tested and working.
.
Who is it for?
Sound designers, soundscape and Foley recordists, and musicians recording acoustic instruments. For anyone who hears a strange little sound and thinks: I could make something with that.
.
What does it do?
Records sound travelling through materials: a guitar body, a vibrating panel, a resonant object. It gives you a different perspective from a microphone in the air.
.
How does it work?
Each pickup feeds its own 4000XL preamp, and each preamp goes to one input on your interface or recorder: two pickups → two preamps → two channels → DAW. These are two mono systems used together, so stereo width comes from placement and mixing. Check phase when you combine related signals.
.
SEE ---> Barcus-Berry Uses

• Foley and sound design: record textures straight from the surface, like creaking wood, scraped metal, glass and paper, with no room sound
• Stereo contact recording: two pickups and two preamps capture a surface in true stereo, for example both ends of a piano soundboard or both sides of a guitar body
• Acoustic instruments: guitar, violin, cello, double bass, mandolin, kalimba and hang drum. Stick-on mounting leaves no marks
• Piano and harp soundboards: a close, clean signal that doesn't pick up the rest of the band on stage
• Percussion: frame drums, cajón, tabla and hand percussion, where you want the body of the drum rather than the room
• Field recording: fences, railings, bridges, pipes and wires. It picks up sound travelling through the material (plug-in power or a 9V battery works away from the studio)
• Experimental and ambient music: amplify springs, toys, bowls and found objects, then feed the result into effects and modular gear
• Live sound: feedback-resistant pickup for acoustic acts, with a balanced XLR out straight to the desk
• Studio DI: the ¼″ input takes other piezo pickups too. It gives them the high 2.2 MΩ input they need, so they sound full instead of thin and quacky
• Monitoring while you record: the monitor output lets you hear the contact sound live while the XLR goes to your recorder

What could you create?

• Guitar: stretch a recorded resonance into an atmospheric texture.
• Percussion: chop taps and scrapes into your own sampler kit.
• Cinema: slow down and layer a creak to build tension under a scene.
• Soundscapes: pan or layer two resonant perspectives into an evolving environment.
• Acoustic instruments: piano or harp soundboards, or guitar-body resonance where mounting is suitable.

In use: Tim Prebble describes using Planar Wave pickups with 4000XL preamps for contact-mic library recordings in his article “The first rule of CONTACT MIC club” on Music of Sound. This is a documented creative use, not an endorsement of this sale.
.
Technical details (4000XL)
2.2 MΩ piezo input · balanced XLR main output · ¼-inch input and monitor output · 48V phantom or 9V battery · main-output pad, ground lift, monitor level. These are the model's published specs.

.
This pair
* Condition: Mint. It's essentially new, boxed, and has been tested. Both systems work.
* Included: two Planar Wave pickups, two 4000XL preamps, box. Exact contents as pictured.
.
Buying from me (I PACK VERY CAREFULLY + VERY WELL)
I pack carefully, send you packing photos and upload tracking. If anything isn't right, tell me and we'll work through it together.

.

Barcus-Berry, Planar Wave, 4000XL, piezo preamp, contact pickup, DI box, stereo pair, sound design, foley, acoustic instrument pickup
