Making way for more gear. Great condition.

Effective against boredom, supporting creative sound design

A unique team play of spring reverberation, analogue multimode filtering, distortion and VCA, modulated by an ultra fast LFO and an envelope that can be triggered in flexible ways – Retroverb Lancet offers a comprehensive arsenal of many-sided effects for different applications. The spectrum by far surpasses classic reverberation, filter sweeps or overdrive because you are able to tweak and bend any parameter fast and intuitively to your liking.

Retroverb Lancet will change the way you work with effects. It becomes part of your sound engine, fires it up and will end up as essential part of your sonic signature.

Source of effectiveness

We designed Retroverb Lancet in a way that it can perfectly handle signals of any kind: Guitars, basses, synthesizers, organs or microphones. On top of that, Retroverb Lancet allows you to create percussive sounds using its crash function.

Retroverb Lancet is a real jack of all trades with character, suited for adventurous sound designers and tinkerers.

Audio Input

• max. input sensitivity: –32 dBu
• impedance: 1 MΩ

Output

• max. output level: 20 dBu
• impedance: 600 Ω

Trigger- and CV-inputs

• audio trigger
• • max. input sensitivity: –32 dBu
  • impedance: 1 MΩ
• gate & CRASH
• • min. voltage: + 4 V
• external cv
• • voltage: ± 10 V

Signal-to-Noise Ratio

• direct: > 80 dB
• effect (filter completely open, no reverb): > 75 dB

Spring Tank

• number of springs: 3
• reverbration decay: between 2.75 db and 4.00 s

Filter

• modes: 24-db-lowpass, 24-db-highpass, 12-db-bandpass
• modulations sources: envelope generator, envelope follower, external CV, LFO

LFO

• frequency range: 0.05 Hz … 300 Hz
• waveforms: ramp up, ramp down, square, sine, S&H, envelope generator

Envelope Generator

• modes: AD, ASR
• attack: 1 ms … 10 s
• decay/release: 1 ms … 15 s

Miscellaneous

• power supply: external DC-adapter with 12 V/1000 mA
• dimensions: 26 cm x 14.5 cm x 8 cm (width x depth x height)
• weight: 0.75 kg

Acessories

• wooden side panels
