TonePort UX2 Ins and Outs:
- Inputs:
- 2x XLR mic preamp inputs with +48V phantom power and trim knobs
- 2x 1/4-inch instrument inputs, including a -10 dB pad input for instruments with high gain output
- 2x 1/4-inch stereo line inputs
- 1/4-inch stereo monitor input
- 2x 1/4-inch footswitch jacks for sending MIDI commands to recording programs (start/stop, punch in/out, etc.)
- S/PDIF stereo output (RCA-type)
- 1/4-inch balanced line outputs with master volume knob
- 1/4-inch headphones output with independent volume knob
- USB bus-powered with LED status indicator
- USB 1.1 & 2.0 compatible
- Rock Solid ASIO, WDM and Mac® OS X driver
Outputs:
Computer Interface:
- Mac:
- Intel® or Power PC® based G4 1.5GHz or better (G4 1.67 or better recommended)
- OS X 10.4 or better
- 512MB RAM minimum (1GB or more recommended)
- 1GB free HD space minimum (10GB or more recommended for recording)
- Drive speed 5400rpm minimum (7200rpm or faster recommended)
- CD-ROM drive
- Internet connection for online features
- Pentium® 4 1.2GHz or better (2.5Ghz or more recommended)
- Windows® Vista and Windows® XP (with SP2 only)
- 512MB RAM minimum (1GB or more recommended)
- 1GB free HD space minimum (10GB or more recommended for recording)
- Drive speed 5400rpm minimum (7200rpm or faster recommended)
- CD-ROM drive
- Internet connection for online features
- One free USB 1.1 or 2.0 compatible port on computer (USB hubs are not supported)
Windows:
USB:
- Line 6® Treadplate
- Line 6® Chemical X
- Line 6® Insane
- Line 6® Piezacoustic 2
- Line 6® Spinal Puppet
- 1953 Small Tweed based on* "wide panel" Fender® Deluxe Reverb®
- 1958 Tweed B-Man based on* Fender® Bassman®
- 1964 Blackface 'Lux based on* Fender® Deluxe Reverb®
- 1967 Class A-30 Top Boost based on* Vox® AC-30
- 1968 Plexi Lead based on* Marshall® Super Lead
- 1968 Plexi Jump Lead based on* Marshall® Super Lead with "jumped" channels
- 1987 Jazz Clean based on* Roland® JC-120
- 1990 Brit J-800 based on* Marshall® JCM-800
- 1993 Solo 100 Head based on* Soldano SLO-100
- 2001 Treadplate based on* Mesa/Boogie® Dual Rectifier®
- Tube Instrument Preamp
- Citrus D-30 based on* Orange® AD30TC
- Brit Gain 18 based on* Marshall® 1974X 18W Reissue
- Rock Classic based on* Ampeg® SVT
- Flip Top based on* Ampeg® B-15A
- Adam and Eve based on* Eden Traveler WT-300
- Silverface Bass based on* 1967 Fender® Bassman® head
- Eighties based on* Gallien Kruger 800RB
- American Classic - Inspired by* an API® lunch box preamp in a classic studio setup:
- API® - 512c Mic Pre
- API® - 550b EQ
- Studer® - 2-inch tape (Including Emphasis/De-emphasis & tape Soft Clip)
- Vintage UK - Inspired by* a Neve 1073
- Modern - Inspired by* an Avalon Vt737
- Console
- Vintage - Inspired by* a Classic Vintage Tube Preamp setup consisting of:
- Requisite Y7 Mic Pre
- API® - 550b EQ
- Studer® - 2-inch tape (Including Emphasis/De-emphasis & tape Soft Clip)
- Lo-Fi
- Compressor (based on* LA-2A® Compressor)
- Noise Gate
- Male De-Esser
- Female De-Esse
- Facial Fuzz (based on* Fuzz Face)
- Fuzz Pi (based on* Big Muff Pi®)
- Screamer (based on* Tube Screamer®)
- Classic Distortion (based on* ProCo Rat)
- Vettaâ„¢ Comp
- Line 6® Sine Chorus
- Line 6® Flanger
- Phaser (based on* MXR® Phase 90)
- U-Vibe (based on* Uni-Vibe®)
- Opto Tremolo (based on* 1965 Fender® Deluxe Reverb®)
- Rotary Drum & Horn (based on* Leslie® 145)
- Analog Delay Modulation (based on* Deluxe Memory Man)
- Tube Echo (based on* EP-1 Tube Echoplex)
- Line 6® Digital Delay
- Standard Spring Reverb
- Brite Room Reverb
- Medium Hall Reverb
- Cavernous Reverb
- Slap Plate Reverb
- Wah (based on* Vox® Wah)
- Volume (Pre- or Post-Amp Routing options)
- Compressor (based on* LA-2A® Compressor)
- Noise Gate
- Female De-Esser
- Male De-Esser
- Bass Overdrive (based on* Sans Amp bass Driver)
- Bronze Master (based on* Maestro® Bass Brassmaster)
- Sub Octaves (based on* L6 original synth effect)
- Weeper (based on* Arbiter® Cry Baby)
This item is sold As-Described
This item is sold As-Described and cannot be returned unless it arrives in a condition different from how it was described or photographed. Items must be returned in original, as-shipped condition with all original packaging.Learn More.
| Listed | 5 years ago |
|---|---|
| Condition | Excellent (Used) Excellent items are almost entirely free from blemishes and other visual defects and have been played or used with the utmost care.Learn more |
