RapCo Horizon DB-1SL Speaker Level Direct Box

The DB-1SL provides the same functions as our DB-1 as well as accepting speaker level input signals (400 watt maximum).  Includes a paralleled 1/4 inch output jack for on-stage monitoring.  Transforms a Hi-Z 1/4 inch input to balanced Lo-Z XLR output.  A ground lift switch is provided for buzz-free operation in almost any environment.

Features

• Speaker Level to Line Level: The DB-1SL converts high-powered speaker level signals to balanced line level, allowing you to connect speakers to mixers, amplifiers, or recording equipment with ease.
• Balanced Output: Provides a balanced XLR output for noise-free, interference-resistant audio transmission.
• Passive Design: No need for batteries or external power sources - the DB-1SL operates passively, making it a reliable and hassle-free addition to your setup.
• Rugged Construction: Built to withstand the demands of professional use, the DB-1SL features a robust and durable enclosure.
• Ground Lift Switch: The ground lift switch helps eliminate ground loop issues, ensuring clean and clear audio quality.
• Compact and Portable: The compact design makes it easy to transport and integrate into your audio rig.

Specifications

• Approximate size: 3 3/4"(w) x 5"(h) x 1 3/4"(d)
• (1) XLRM       XLR male panel mount
• (2) 1/4             Stereo panel mount
• (1) DBT          Transformer
• (2) Switches    Panel mount switches, 1 for ground lift, 1 for speaker pad
