Voodoo Lab Pedal Power 2 plus in mint condition. With the brackets installed (for going in the Pedal train classic PT 2 HC, which I also sell, see related listing.

Exact specs:

8 isolated outputs sections eliminate ground loops and hum

• All outputs compatible with 9V battery-operated pedals
• Toroidal transformer and linear regulation for lowest possible noise
• Delivers clean, consistent power even with poor AC line conditions
• 200-watt courtesy AC outlet for powering additional devices
• Hand-built in the USA

• 230V 50/60Hz (Europe/Australia model)
• 5.5x2.1mm barrel connectors - center negative
• Short circuit protected
• Included Cables (Standard polarity DC cable 8-pack)
• Custom-designed, ultra-low noise toroidal power transformer
• Rear Courtesy Auxiliary AC outlet, 200 watts max
• Dimensions: 6" x 3.4" x 1.8"(152 x 86 x 44 mm)
• Weight: 2 lbs. (907g)

Pedal Power 2 PLUS Outputs

9/12V (x4) – Standard 9V and 12V Boss ACA
With each one of these four outputs delivering 100mA, you can easily power any 9V battery-operated pedals. Boss pedals that specify the PSA adapter operate at 9V like most other pedals. Boss pedals that require the ACA adapter operate at 12V which can be selected via switches underneath the Pedal Power 2 PLUS. Any one of these outputs can be individually selected to run at 9V or 12V.

9V (x2) – High Current 9V and Line 6 Modelers
These two outputs each deliver 250mA allowing you to run high current draw effects like the Boss DD-20 Giga Delay or Line 6 DL4 Delay Modeler. Via switches underneath the Pedal Power 2 PLUS, these two outputs can be separately configured for regulated (Boss Twin Pedals) or unregulated (Line 6 Modelers) power allowing you to run both units if so desired. These outputs can also power any standard 9V effects as well.

9V (x2) – Standard 9V With Battery Sag Control
These outputs each have an available 100mA of power, but also allow you to SAG the voltage from roughly 4V to 9V. The SAG control is mostly useful for transistor-based fuzz, octavia, and distortion circuits, as most modern opamp designs are minimally affected by variations in supply voltage.

18V/24V – Using Custom Cables
All of the outputs on the Pedal Power 2 PLUS (and the original Pedal Power) are completely isolated allowing you to create different voltages. You can run effects like the current MXR Flanger by combining two 9V outputs to create a single 18V supply. By switching two outputs into 12V ACA mode, you can join them together to create a 24V output for powering numerous Electro-Harmonix stompboxes including the Deluxe Memory Man.

Shipping fees maybe lower when I get your details, as I will try to find the cheaper way to send. Overseas / rest of the world contact me to find the most economical way to ship. If in Athens, we can arrange local pickup for free.

Shopping from Purple Armchair Guitars & Gear, apart from having a selection of classic guitar gear to chose, helps a fellow musician suffering from debilitating hand illness to better his life (see shop description)

Thanks,

Konstantinos
