Product Features:

• Classic Wah tone recreates vocal sweeps and lush harmonics Solid metal shell Touch-sensitive on/off operation True bypass Mini size footprint for space saving and portability Extendable pedal ring creates larger contact area and therefore enhances sensitivity 9 V power supply
• The Wahter recreates the vocal sweep and lush harmonics of the classic wah tone, while remaining small and compact
• The smoothness of tone is all thanks to the high-quality electronic components Mooer uses
• Unlike the traditional way of turning on/off the wah pedal, The Wahter is equipped with four pressure sensors
• Simply put your foot on the pedal, and the pressure sensor will sense your touch


Specifications:

• Signal Input:  1/4" Monaural Jack (impedance: 1M Ohms )
• Signal Output: 1/4" Monaural Jack (impedance: 100Ohms)
• Power Requirements: AC adapter 9V DC (center minus plug),recommended to use Mooer Micro Power(not include)
• Current Draw: 50mA


Note:

• 1.Power adapter is not included.
• 2.Please use the 9V power adapter whose polarity is positive pole outside and negative pole inside. Otherwise, the product may not work properly.
• 3.Plug an instrument cable from your guitar to the pedal's input jack and plug another instrument cable from the pedal's output jack to your amp or pedalboard.
• 4.To turn the pedal on, simply put your foot on the pedal .The pressure sensor will sense your touch, and the LED will illuminate, indicating the wah effect is in operation.
• 5.To turn the pedal off simply remove your foot from the pedestal and it will deactivate.


Package Includes:

• 1 * Guitar Effect Pedal
• 1 * Linking Tape
• 1 * User Manual(English)
