BH5 Little Giant
Our users rate Reverb
TECHNICAL SPECIFICATIONS
Output Power Rating
Pentode: 5 W rms @ 22% THD, 16 ohm load
Triode: 3 W rms @ 9% THD, 16 ohm load
Signal-to-Noise Ratio
63 dB, Typical
Input Impedance
1 Meg Ohm
EQ
Treble: 20 dB range @ 10 kHz
Middle:
7 dB range
@ 1 kHz
Bass:
11 dB range @ 100 Hz
Preamp Tube
1 x 12AX7/ECC83
Power Tube
1 x EL84/6BQ5
Rectifier
Solid State
Speaker Specs
Custom Designed Eminence Blackheart Speaker
Model 1216A, American Voiced, 12", 75 W, 16 ohm, 1.75" voice coil diameter, 34 oz magnet
Speaker Outputs
1 x 16 ohms
2 x 8 ohms (8 ohms total load impedance required)
2 x 4 ohms (4 ohms total load impedance required)
Power Requirements
220/240 VAC, 50/60 Hz, 45 VA
110/120 VAC, 50/60 Hz, 45 VA
AC Mains Fuse
100/120 VAC: T2.AL 250V Fuse
220/240 VAC: T1.AL 250V Fuse
Size (H x W x D)
18.6 in/473 mm (including feet) x 18.0 in/460 mm x 11.0 in/280 mm
Weight
38.6 lb/17.5 kg
The Blackheart Little Giant 5 112 Combo is covered with a durable fabric-backed vinyl material. Wipe it clean with a lint-free cloth. Never spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish.
This item is sold As-Described
This item is sold As-Described and cannot be returned unless it arrives in a condition different from how it was described or photographed. Items must be returned in original, as-shipped condition with all original packaging.Learn More.
