Features
• Included Arturia instruments - 500 vintage & modern keyboard presets with Analog Lab Intro
• Tutorials - Learn recording and music production with MiniFuse, starting with the basics
• Exclusive content - Tips, tricks, and advice from industry experts
• Dedicated online portal - Access everything you need online in one place
• Subscriptions - Complimentary introductions to world-class audio & mixing services
• 1 x combo Mic/Inst/Line XLR Input with 48V phantom power
• 2 x 1/4" TRS balanced line outputs with volume control
• 1 x stereo headphone output with volume control
• Direct Monitor switch
• 1 x USB2 type A hub (250mA max.)
• 1 x stereo virtual loopback channel
• USB-C interface compatible with PC and Mac, fully USB 2.0 compatible
• Bus-powered

Specifications
Line Inputs
Input impedance: 16kΩ
Maximum input level: +22dBu
Gain range: 56dB
Frequency response 20Hz to 20kHz: +/-0.05dB (min gain)
Dynamic range: 110dB typical (A-weighted)
THD+N @ 1kHz: -100dB typical (un-weighted)
Instrument Input
Input impedance: 1MΩ on Tip
Maximum input level: +11.5dBu
Gain range: 56dB
Frequency response 20Hz to 20kHz: +/-0.06dB (min gain)
Dynamic range: 110dB typical (A-weighted)
THD+N @ 1kHz: -91dB typical (un-weighted)
Microphone Preamps
Input impedance: 2.5kΩ
Maximum input level: +9dBu
Gain range: 56dB
Equivalent Input Noise (EIN): -129dB typical (A-weighted)
Frequency response 20Hz to 20kHz: +/-0.06dB (min gain)
Dynamic range: 110dB typical (A-weighted)
THD+N @ 1kHz: -100dB typical (un-weighted)
Speakers
Output impedance: 94Ω
Maximum output level: +12dBu
Frequency response 20-20kHz: +/-0.09dB
Dynamic range: 107.5dB typical (A-weighted)
THD+N @ 1kHz: -101dB typical (un-weighted)
Phones
Output impedance: 10Ω
Maximum output level: +11.4dBu
Frequency response 20-20kHz: +/-0.09dB
Dynamic range: 104dB typical (A-weighted)
Power @ 33ohm: 137mW
Supported Sample rates
44.1kHz, 48kHz, 88.2 kHz, 96kHz, 176.4kHz, 192 kHz
