Playing guitar in a great sounding room is the most inspiring, engaging playing experience imaginable - far more enjoyable than in a dry-sounding room like a lounge, office or den. Yamaha's TransAcoustic Guitar recreates the incredible experience of playing in a rich, live room without needing any external amplification or effects - just the guitar itself. Whether you're practicing, writing, recording or just playing for fun, the TransAcoustic Guitar will make you play better, longer and with more creativity. Once you've experienced it, you'll never want to play another acoustic guitar again.

Actuator
An actuator installed on the inner surface of the guitar back vibrates in response to the vibrations of the strings. The vibrations of the actuator are then conveyed to the body of the guitar, and to the air in and around the guitar body, generating authentic reverb and chorus sounds from inside the body.

Controls
Three simple knobs let you adjust the degree of effect applied and the lineout volume level. Additionally, keeping the controls small minimizes the area of the holes in the body material, reducing acoustic sound loss.
(A) Chorus Control
(B) Reverb Control (Room / Hall)
(C) TA Switch / Line Out Volume Control
• Pressing the TA Switch for more than 0.3 seconds activates the TA function.
• When a cable is connected to the line-out jack, the line-out volume can be adjusted by rotating the (C) knob.

Newly Designed Battery Box
Battery box integrated into the end-pin jack. This requires fewer holes in the body, thus reducing acoustic sound loss. Connect the cable from the jack to a PA or amp to use as an acoustic electric guitar.

Features
• Compact body
• Solid spruce top
• Mahogany back & sides
• On-board reverb and chorus effects - no need for an amp or other external gear
• Durable hard bag included

Specifications
Body Shape: CSF
Scale Length: 600mm (23.6")
Body Length: 450mm (17.71")
Total Length: 940mm (37.00")
Body Width: 340mm (13.38")
Body Depth: 85-105mm (3.34" - 4")
Nut Width: 43mm (0.43")
Top Material: Solid Sitka Spruce
Back/Side Material: Mahogany
Neck Material: Nato
Fingerboard Material: Rosewood
Fingerboard Radius: R400mm (16")
Bridge Material: Rosewood
Nut/Saddle Material: Urea
Bridge Pins: Black ABS with White Dot
Tuners: Die-cast Chrome
Body Binding: Black & White
Soundhole Inlay: Abalone & Black
Pickguard: None
Body Finish: Gloss
Neck Finish: Matte
Electronics: SYSTEM70 TransAcoustic
Controls: Reverb / Chorus / Line Out Vol(TA On/Off)
Connections: LINE OUT
Strings: Elixir NANOWEB 80/20 Bronze Light
Accessories: Hex Wrench, 2 x AA Batteries
Case: Hard Bag
