Genuine Grover Original Rotomatic 3x3 Black Chrome
P17Manufacturers Part Number: 102BC

The 102 Series machine heads are a triumph in engineering and styling. The housing provides a maximum bearing for worm, gear, and string post. Gear ratio is 14:1. Worm and gear are precision-cut for perfect meshing, which eliminates backlash and slippage. Countersunk tension screw permits player to regulate turning tension to any degree. Enclosed gear box with special lubricant for a lifetime of trouble-free service.

• Sealed-in, lubricated gears
• 14:1 gear ratio
• 25/64” post hole
• Post length to hole: 23mm
• Overall post length: 28.2mm
• Weight per pc/per set: 1.6oz/9.6oz
• Max. string gauge: .074”
• Hardware included (bushings, washers, screws)

• Drop-in replacement for:
102-18 Series
102V Series
103 Series
106 Series
109 Series
109-18 Series
135 Series (Top mounting hole will be visible)
136 Series (Top mounting hole will be visible)
502 Series
509 Series

Available in:
For standard guitars, 3 Treble and 3 Bass, Set of 6
No. 102N Nickel
No. 102C Chrome
No. 102G Gold
No. 102BC Black Chrome

W/ Keystone Buttons
For standard guitars, 3 Treble and 3 Bass, Set of 6
No. 102NK Nickel
No. 102CK Chrome
No. 102GK Gold
No. 102BCK Black Chrome

Buy with confidence from SportHiTech, an authorized Grover Dealer. All products are factory fresh and in original retail packaging.
