Tube-Tech CL 1B Compressor

TUBE-TECH CL 1B Compressor features a gain-reduction element, positioned immediately after the input transformer. It is controlled by the sidechain amplifier, which also contain the two time control circuits – one for fixed and one for variable Attack/Release. The two time-controllers can either be used separately or combined. This circuit contains semiconductor OP-amps for the entire control.

The gain-reduction element is followed by a tube-based push-pull amplifier with variable gain up to 30 dB. A dedicated Bus selector with three positions (Off, Bus 1, Bus 2) is used whenever you want to link several compressors together. Input and output transformers have a static-screen between the primary and secondary wirings. Both Input and Output are balanced as well as fully floating.

Features:

• Unique low distortion gain-reduction element
• All tube-based push-pull amplifier
• Multiple interconnection of several compressors via two busses
• VU-meter for monitoring input, compression and output
• Continuously variable attack and release time
• Gain Range (off to +30 dB)
• Variable Threshold (off to -40 dBu)
• Frequency response @ -3 dB: 5 Hz to 25 kHz
• Low noise: < -75 dBu @30 dB gain
• Clickless bypass relay

Tech SpecsNUMBER OF CHANNELS1CONTROLSGain, Ratio, Threshold, Attack, ReleaseTHRESHOLD-40dB to 0dBRATIO2:1 to 10:1FREQUENCY RESPONSE5Hz-25kHz @-3dBSIDE CHAIN INSERTSYesINPUTS1 x XLROUTPUTS1 x XLRSIDECHAIN I/O2 x 1/4″RACKMOUNT SPACES3UHEIGHT5.25″DEPTH6.7″WIDTH19″WEIGHT9 lbs.MANUFACTURER PART NUMBERCL 1B
