Dangerous Music Monitor SR Expansion Module
14-Day Return Policy
Enjoy peace of mind with your new gear
Our users rate Reverb
The Dangerous Music Monitor SR Expansion Module features all the same specs as the Monitor ST, as the SR is an expansion module that converts your Monitor ST into a surround sound monitor controller, allowing for expanded monitoring capabilities - which can come in handy with the rising interest and growth in Dolby Atmos.
The Dangerous Music Monitor SR Expansion Module turns the award-winning into a versatile surround monitoring system. Need to work in 5.1, 7.1, 10.2? No problem, just include as many SR units as needed. The MONITOR-ST/SR combo is simply the most accurate, clear, and flexible surround monitoring solution available.
Designed by the legendary Chris Muth, the MONITOR- ST/SR system handles all of your input sources and speaker routing with crystal clarity and massive headroom delivered from a meticulously designed circuit built from only the highest quality components available. With its relay-actuated analog stepped attenuator, ever-expandable input channels and speaker outs, programmable I/O levels, all controlled via the sleek remote control, you can accurately dial in even the most elaborate surround systems for rock-solid imaging and crystal clarity. And because all the switching within the MONITOR-ST/SR combo is handled by relays, your audio signals are delivered to your speakers unadulterated, removing all the guesswork while tracking, mixing, or mastering.
Dangerous Music Monitor SR Expansion Module Features
- Hand assembled in the USA
- Audiophile-grade components throughout for crystal clear monitoring
- Expand the MONITOR-ST into an elegant surround system
- Programmable remote tethered by a single Cat 5e shielded cable
- Customize the analog inputs, speaker sets and dedicated subwoofer output
- Audiophile-grade analog stepped-attenuator volume control
- Adjust for and store level offsets for different devices
- Dedicated meter outputs
- Use with for direct remote control integration and unmatched clarity
Dangerous Music Monitor SR Expansion Module Specifications
- Gain Tracking Accuracy: better than 0.05dB for 6 channels
- THD+N: 0.002%
- IMD: 0.003%
- Frequency Response: 1Hz-100kHz -0.1 dB
- Crosstalk Rejection: >95dB
- Nominal Input Level: +4dBu or -10dBV
- Crossover: -3dB @57Hz 18dB/Octave modified Butterworth/Chebyshev
- Headphone Amp: 0.002% THD+N
- Headroom: +25 dBu to main outputs
- Dynamic range: 110dB
- Maximum level: +25dBu
Dangerous Music Monitor SR Expansion Module Includes
- Monitor SR Expansion Module
- Power Supply
- Cat5 Cable
- 2 Ribbon Cables
- Manufacturer Warranty
| Condition | Brand New (New) Brand New items are sold by an authorized dealer or original builder and include all original packaging.Learn more |
|---|---|
| Brand | |
| Model |
|
| Categories | |
| Electronics |
|
| Format |
|
