John Bowen Solaris 2014 White

Sorry, this listing is no longer available.

Sold!


This is a beautiful John Bowen Solaris, serial #210 with transparent and illuminated mod wheels.
It's an incredible sound design synth, with an incredible layout.

It's in excellent (no known blemishes, used in 1 non-smoking studio) condition, and an amazing synth. I'm sorry to have to part with it, but an impending move forces the sale.

The first photo (on wood floor) is not of the synth for sale, but was a much better photo than i could take!



If you don't know about this synth, i highly recommend heading to








Solaris - Specifications OscillatorsFour (4) oscillators. Each can be of the following types:
• MultiMode (standard waveshapes, combinations, plus saw stack)
• WaveTable (wavetables 1-64 from the Waldorf Microwave synthesizers)
• Sample playback (.raw format)
• CEM VCO chip model (like those used in the later Rev. 3.x versions of the Prophet 5)
• All of the waveforms used in the Prophet VS
• (temperature stable) model of the oscillator used in the MiniMoog.
RotorsTwo (2) rotors which are special sound sources, implemented as a looping wavesequence of four (4) assignable inputs, played successively.PolyphonyThe Solaris provides 10 voices of polyphonyAmplitude ModulatorsTwo (2) Amplitude Modulation sections that multiply the two inputs, carrier and modulator. The four algorithms are Shift, Clip, Absolute, RingFiltersFour (4) filters. Each can be of the following types:
• a MultiMode filter with 23 different modes, including 4, 3, 2, & 1 pole settings of Lowpass and Highpass, several Bandpass and Band Reject (Notch) plus some series combinations. This filter design is based on the CEM VCF chip model (like those used in the later Rev. 3.x versions of the Prophet 5)
• SSM VCF chip model (like those used in earlier Rev. 1 and Rev. 2 versions of the Prophet 5) - this filter does not have gain compensation
• model of the MiniMoog 'ladder' filter
• model of the Oberheim State Variable Filter (found in earlier Oberheim synthesizers), Lowpass, Highpass, Bandpass, Band Reject (Notch)
• Comb filter (two types, with positive and negative feedback).
• Vocal formant filter (a set of 5 vowel sounds that can be crossfaded)
MixersFour (4) mixers, each with four inputs. The Inputs are freely assignable using any audio source. Insert Effects can be inserted post-mix before these feed into their respective filters.Vector MixersTwo (2) separate vector mixers, each with four (4) inputs assignable to the cardinal points of the built-in joystick for manual blending.Envelope Generators (EGs)Six (6) EGs, each with five (5) stages - Delay, Attack, Decay, Sustain and Release.Looping Envelope GeneratorOne looping envelope generator, with eight (8) stages. Variable Loop Start and Key Off (Sustain) points. Times and Levels can be modulated, and output is bi-polar.Low Frequency Oscillators (LFOs)Four (4) LFOs plus one (1) LFO dedicated (i.e., already pre-wired) to oscillator frequency as Vibrato LFO. Each LFO offers control over delayed start, fade-in and fade-out times, MIDI clock, key sync and phase control.ArpeggiatorThe Arpeggiator has a wide variety of modes, and can be transposed from the keyboard using an assignable switch function.Four Row Step SequencerFour (4) rows of step sequencer control - Seq A, B, C, & D. Values are +/- 127, or Rest for Row A, which controls the rhythmic pattern for all 4 rows, however, each row can be set to a different step length of 1 to 16 steps. Each sequence row's output is freely assignable through the system. Sequences can be stepped through via key event as well as normal and non-retriggering modes.Lag ProcessorsFour (4) Exponential Lag Processors to smooth out control signals.Key TablesFour (4) programmable Key Tables. Users can set a value from 0-127 for each MIDI Note number/key. Values are interpolated where they are not specifically entered by the user.EffectsPhaser, chorus/flanger, delay, and 3-band EQ effects are available. The series order of the FX is user-definable. There are also three (3) Insert Effects, which can be pre- or post-filter. These are Decimation, BitChop, and Distortion.Audio Inputs & OutputsFour (4) External analog inputs. Eight (8) analog outputs, configured as four stereo pairs. 1/4” jacks, balanced. S/PDIF optical In and Out. All inputs (including S/PDIF) can be selected as Audio Sources throughout the synthesizer for further processing or use as modulation sources.KeyboardFatar manufactured TP-8, 61-key weighted, dynamic bubble contact, monophonic after-touch stripPerformance controls
• two wheels (pitch and modulation)
• joystick
• 750mm ribbon controller
Main displayone (1) 240 x 64 backlit graphic displaySection displaysfive (5) 2 x 40 backlit character displaysMIDIIn/Out/Thru jacksUSByou can use USB instead of MIDI. the Solaris will be recognised as a MIDI usb devicePower120-240V (AC)Dimensions39" x 16.73" x 6" (WxDxH) 98 x 42.5 x 15 cm (WxDxH)Weightapproximately 33 pounds (15kg)

This item is sold As-Described

This item is sold As-Described and cannot be returned unless it arrives in a condition different from how it was described or photographed. Items must be returned in original, as-shipped condition with all original packaging.

Product Specs

Condition:
Excellent (Used)
Brand
John Bowen
Model
Solaris
Finish
White
Categories
Digital Synths
Year
2014
Made In
United States
