Description

Prismatic Sound Modeling technology gives this sound module a high-quality sound with the expressive power of acoustic drums. 3 digital trigger-ins provide natural drum playing expression. The module also features a wealth of practice functions and Bluetooth connectivity for easy training. The TD-27 can also be used for easy training.

The TD-27 is equipped with "Prismatic Sound Modeling," which has been well-received by the TD-50, and is also equipped with the PD-140DS, which is equipped with a multi-element sensor.

The TD-27 is a combination of over 20 years of V-Drums' advanced sampling and modeling technology.

V-Drums' more than 20 years of advanced sampling and modeling technology has been organically combined to deliver the highest level of expression and playability of electronic drums.

VAD506 and VAD506 can be connected to digital pads such as the VAD506 and VAD506.

The TD-27, the sound source for the VAD506 and VAD503, features 55 new presets focused on acoustic kits.

The VAD506 and VAD503 are equipped with 55 new presets focused on acoustic kits. The TD-27 is a V-drum sound source that will satisfy all drummers.

The TD-27 is equipped with "Prismatic Sound Modeling," a proprietary modeling technology that has been well received by the flagship TD-50. This technology delivers a rich and expressive drum sound with a vivid resonance. 2.

2. Supports the connection of digital pads equipped with multi-element sensors.

3. Enhanced number of built-in instruments with 55 new preset kits.

4. New "PureAcoustic Ambience technology" to maximize acoustic sound.

　　EQ, comps, and transients essential for sound creation.

The 28-output/4-in USB audio interface is convenient for multitrack recording on a PC.

　　USB audio interface for multitrack recording on a PC. 6.

6. Bluetooth wireless connection to mobile devices such as smartphones for audio playback from the TD-27.

Two direct outputs for live performances and recording.

Number of drum kits: 100 (55 presets)

Number of voices: 728

Number of user samples: Up to 500 user samples (including factory default user samples); total sound length: 24 minutes mono, 12 minutes stereo; importable file format: WAV (44.1 kHz, 16/24-bit)

Effects: Pad compressor (per pad), pad equalizer (per pad), overhead mic simulator, room/reverb, multi-effects: 3 channels/30 types, master compressor, master equalizer

Bluetooth support = Bluetooth standard Ver 4.2, supported profiles = A2DP (audio), GATT (MIDI over Bluetooth Low Energy), supported codecs = SBC (supports SCMS-T content protection)

Song Player (SD card): File format: WAV (44.1 kHz, 16/24 bit), MP3 * Audio files must be stored on the SD card.

Recorder: Recording method = real time, maximum recording time = 60 minutes (temporary recording: 3 minutes)

　Recorder: Recording method = real time, maximum recording time = 60 minutes (temporary recording: 3 minutes) * SD card is required for recording; if no SD card is present, temporary recording of approximately 3 minutes is possible, but cannot be saved to the main unit.

　File format = WAV (44.1 kHz, 16 bit)

Display: Graphic LCD 256 × 80 dots ● External memory: SD card (SDHC compatible)

Connection Terminals

　TRIGGER INPUT jack × 1 (kick, snare, tom 1, tom 2, tom 3, hi-hat, crash 1, ride, ride bell, hi-hat control): 25-pin D-sub type * Exclusive use with pads supporting digital connection.

　TRIGGER IN jacks x 4 (Crash 2, AUX 1, AUX 2, AUX 3): TRS standard type

　DIGITAL TRIGGER IN jacks x 3: USB A type, MASTER OUT jacks x 2 (L/MONO, R): standard type, DIRECT OUT jacks x 2 (MONO) standard type

　PHONES jack x 1: stereo standard type, MIX IN jack x 1: stereo standard type, MIDI jack (IN, OUT/THRU), USB COMPUTER jack x 1: USB B type, FOOT SW jack x 1: USB B type

　FOOT SW terminal x 1: TRS standard type, DC IN terminal

USB COMPUTER terminal Speed = Hi-speed USB, driver mode = Generic/Bender, supported communication = USB-MIDI / USB-Audio

　To use USB audio, it is necessary to change to bender mode and use the bender driver.

USB audio Sampling frequency (original) = 44.1 kHz, Sampling frequency (with sampling rate converter) = 96 kHz, 48 kHz, Recording = 28 channels, Playback = 4 channels

Power supply: AC adapter (9 VDC) ●Current consumption: 770 mA　

Accessories: Quick Start (including warranty card), AC adapter, dedicated connection cable, user registration card, "Safety Precautions" leaflet, sound source mounting plate, thumbscrews (M5 × 10) × 2 * SD card not included.

Optional accessories

　Pads: PD series, PDX series, BT series

　Cymbals: CY Series

　Kick: KD series, KT series

　Hi-hat: VH-13, VH-11, VH-10

　Hi-hat control pedals: FD Series

　Acoustic drum triggers: RT Series

　Footswitches: BOSS FS-5U, FS-6

　Personal Drum Monitors: PM Series

　Noise Eater: NE Series

External Dimensions: 238 (W) x 204 (D) x 79 (H) mm　

Weight (excluding AC adapter): 1.1 kg
