This Choral Reef uses an industrial-grade Carling P-H551 switch that requires less force to depress.

The new Choral Reef design boasts two high headroom MN300x chips that can run on up to 15V for maximum clean headroom. The 256-stage MN3009 chip has a shorter delay time that is perfect for creating flanger & vibrato tones, and the 1024-stage MN3007 chip has a longer delay time tailor-made for dripping, wet chorus effects. But wait, there's more! Put the MODE switch in the middle, and both chips get mixed together for a unique, rich chorus tone.

SPEED - controls the speed of the chorus
DEPTH - controls the depth of the chorus
MIX - blends between the dry and wet signals
TIME - controls the delay time of the chorus line, which affects the flavor of the
chorus (longer delay times increase the noise of the BBD chip)
FEED - adds feedback into the circuit, adding resonance & repeats with longer delay times
MODE - toggles between the 256-stage MN3009 bucket brigade chip and the 1024-stage MN3007 chip.

INTERNAL CONTROLS - The right trimpot controls the max feedback level, the left trimpot biases the bucket brigade chip for maximum headroom, and the bottom changes the brightness of the LED indicator.

POWER - Accepts the industry standard, 9 to 15 VDC, negative-tip power supply. It CANNOT be powered with a 9V battery.

FREE SHIPPING via USPS Priority inside the USA, $18 to Canada & $25 everywhere else with USPS First Class International. All VFE Pedals include a 1-year warranty on parts & labor.
