Klark Teknik DN6000 Real Time Audio Analyser 2000 - SILVER
This gear has sold
See similar gear from other Reverb sellers
Our users rate Reverb
DescriptionKlark Teknik DN6000 Real Time Audio Analyser
The ability to monitor and analyse audio systems, regardless of their application, remains one of the most important issues facing engineers. The DN6000 Audio Analyser continues Klark Teknik’s long tradition of providing audio professionals with the tools they need in the field, with a unique feature set that provides every important analysis function in one roadworthy device.
Specifications:
- Frequency Response: 5Hz to 40kHz
- Microphone Input One, Differential (Compatible with microphone sensitivities from 0.25mV/uBar to 1mV/uBar)
- Sensitivity: 140dBSPL to 50dBSPL (with optional 6051 microphone)
- Powering: 48V DC phantom power (nominal)
- Connector: XLR on front panel
- Line Input: Two, Differential (balanced or unbalanced)
- Sensitivity: +40dBu to -50dBu
- Impedance: 47kΩ
- Connector: XLRs on rear panel
- Pink Noise output:
- Type: Digital pseudo-random white noise generator with pink noise filter
- Frequency distribution: -3dB/Octave, 20Hz to 20kHz ±0.2dB
- Level: +4dBu, -10dBu, -30dBu
- Impedance: 50Ω balanced
- Connector: XLR on rear panel
- Filters:
- Attenuation accuracy: ±0.1dB
- ‘A’-weighting: Selectable to IEC 651 type 1 requirement
- ‘C’-weighting: Selectable to IEC 651 type 1 requirement
- Interfaces: DN9340, parallel printer, RS-232 serial port via external computer
- Terminations:
- Audio inputs/outputs: 3 pin XLR
- Mic: 3 pin XLR
- Printer Port: 25 way D socket
- Data Output: 16 way IDC Latching Header (Male)
- RS-232: 9 way D socket
- Power: 3 pin IEC
- Power requirements:
- Voltage: 100 to 240V, 50 to 60Hz
- Consumption: < 40VA
- Dimensions:
- Height: 89mm (3.5 inch) - (2U)
- Width: 482mm (19 inch)
- Depth: 302mm (11.8 inch)
- Weight:
- Net: 5.5kg
- Shipping: 9.5kg
- 6051 Microphone:
- Frequency Response: Flat to 15kHz
- Sensitivity: 0.5mV per uBar nominal @1kHz
- Dynamic range: 20 to 130dBSPL
- Capsule: 0.25 inch electret condenser
- Type: Pressure - omnidirectional
- Power required: 14V minimum phantom power (compatible with 48V)
This item is sold As-Described
This item is sold As-Described and cannot be returned unless it arrives in a condition different from how it was described or photographed. Items must be returned in original, as-shipped condition with all original packaging.Learn More.
| Listed | 2 years ago |
|---|---|
| Condition | Very Good (Used) Very Good items may show a few slight marks or scratches but are fully functional and in overall great shape.Learn more |
| Brand | |
| Model |
|
| Finish |
|
| Categories | |
| Year |
|
| Made In |
|
