For sale is an AKAI GX 4000DB 4 track 2 channel stereo Reel to Reel tape deck recorder. Compact size. Easy loading. Durable. Great fidelity. Just a few of the many attributes the GX-4000D is known for. This unit plugs in, powerson, but it doesn't play properly forward or backward. Please see YouTube video. For this reason, I am listing for parts or repair.

------------------------------------------------------

The GX-4000DB is an attractively designed compact tape deck offering multiple connections and controls and quality features among which are Akai's one micron gap heads for high density recording and the well known Dolby Noise Reduction System.

Tape Head

Akai's one-micron gap head is responsible for an amazingly important difference in tape recording. It's the difference between ordinary performance and high density quality recording and playback. Ordinary head gaps are from 2 to 4 microns, but the gap of this outstanding head is only one micron. This high density recording system provides excellent frequency response and clear, high pitched sound is generated as a frequency tone and recorded smoothly without distortion.

Dolby Noise Reduction

With the Dolby Noise Reduction System, hissing noise heretofore thought impossible to eliminate, is reduced to a completely inaudible level. Basically, this circuit boosts the low level signals prior to recording and lowers them by precisely that same amount at playback time. During this revolutionary process, the extraneous noise is eliminated, thus also eliminating tape hiss.

Dual Monitoring

A Tape Monitor Switch and three heads facilitate instant comparison of the recording being made with source signals. Easy confirmation of recording quality results in a more professional recording. The 4000DB is also equipped with a front panel headphone jack for monitoring or private headphone listening.

Sound on Sound Recording

Sound-On-Sound is the accumulation of as many individual recordings on a single track as is desired. For instance, record on track 1 and rewind tape. While monitoring the first recording through headphones, record on track 3. Both recordings will merge on track 3. Repeat as many times as is desired by switching Track Selector positions. Convenient for fun or professional use.

Sound with Sound

Record on one track, then rewind tape and record on another track while listening to first recording through headphones. Playback and compare! Especially convenient for repetition and comparison exercises such as when studying a foreign language, etc.

Sound Mixing

Independent line and microphone recording level controls and input jacks enable signals from microphone and line sources to be blended and recorded simultaneously. Record your own vocal style accompanied by your favourite orchestra, etc. Interesting and entertaining.

Automatic Shut Off

Threading the tape through the Automatic Shut-Off Lever and setting the Power Switch to Shut-Off position is all that is necessary to effect Automatic Shut-Off at the end of the tape. A convenient safety feature should the unit be left unattended.

Pause Control

Momentarily stops tape travel during recording or playback. Pause control is especially useful when editing tapes. Simply lift Pause Lever when a certain portion of the program is not desired. Easy Start Button release.

VU Meters

Internally illuminated expanded scale VU Meters provide quick and accurate determination of recording and playback levels.

Sturdy Mechanism

In keeping with Akai's top quality parts utilization policy, the 4000DB also features robust construction and sturdy mechanism. Further, a highly efficient induction type motor assures stable tape travel and ideal starting torque. The characteristics of this motor coupled with a boldly designed flywheel reduces wow and flutter significantly.

Specifications:

  • Track system: 4-track, 2-channel, stereo/monaural system
  • Heads: 1 x record, 1 x playback, 1 x erase
  • Motor: 1 x 4-pole induction
  • Reel size: up to 7 inch reel
  • Tape speeds: 3 3⁄4  7 1⁄2 ips
  • Wow and flutter: 0.15% (7 1⁄2 ips)
  • Frequency response: 30Hz to 23kHz (7 1⁄2 ips)
  • Signal to Noise Ratio: 55dB
  • Total harmonic distortion: 1%
  • Crosstalk: 40dB
  • Input: 70mV (line), 0.4mV (mic)
  • Output: 0.775V (line)
  • Semiconductors: 27 x transistors, 2 x FET, 4 x IC, 17 x diodes

Reverb Buyer Protection

Reverb has your back if your item is lost, damaged, or doesn't match its description. Simply report any issues within 7 days and we'll help you get a full refund.Learn more about Reverb Buyer Protection.

Listed3 months ago
ConditionNon Functioning (Used)
Non-functioning items do not work as they should. All known issues should be described in the listing description.Learn more
Brand
Model
  • 1/4" 4-Track 2-Channel Tape Recorder
Finish
  • Silver
Categories
Year
  • 1978 - 1985
Made In
  • Japan
