Kenwood KW-5066 Stereo 4 head reel to reel Tape Deck Vintage Serviced

Kenwood KW-5066 Stereo 4 head reel to reel Tape Deck

Manufactured in 1970

This vintage reel to reel tape deck is one beautiful piece of machinery

This deck has four heads which allows for fast reverse erasing

has had new belt installed

all pulleys have been oiled

New led lights installed

Tape head has been cleaned with American recorder S – 721H professional cleaning solution

and demagnetized

All the internals have been clean and checked out.

This unit has been professionally cleaned and refurbished

Check out the YouTube video for a quick demo

Comes with tape deck, hubcaps, and one take up reel

See specs below

Track system: 4-track, 2-channel, stereo/monaural system

Heads: 1 x playback, 1 x record, 1 x erase, 1 x full track erase

Reel size: up to 7 inch reel

Equalization: NAB

Tape speeds: 1 7⁄8  3 3⁄4  7 1⁄2 ips

Wow and flutter: 0.15% (7 1⁄2 ips)

Frequency response: 25Hz to 20kHz (7 1⁄2 ips)

Signal to Noise Ratio: 50dB

Total harmonic distortion: 0.6%

Input: 100mV (line), 9.8mV (DIN), 0.55mV (mic)

Output: 0.775V (line), 0.775V (DIN)

Semiconductors: 19 x transistors, 2 x diodes

Dimensions: 16.5 x 7 x 15.5 inches

Weight: 24lbs
