Fullerton™ 5G9 Tweed Tremolux

Fullerton™ 5G9 Features:

• “Normal” channel is re-voiced with a JMP50 lead spec-inspired preamp with a channel jumper feature on the volume’s push/pull pot
• “Bright” channel is a stock 5G9 Bright channel voicing that can be switched between a 12AY7 or a 12Ax7 with the volume’s push/pull pot
• Tone control uses a push/pull pot; in for the stock 5G9 gain structure; pull for an added gain stage borrowed from it’s 6G3 cousin
• Rich Mod II PPIMV (Post Phase Inverter Master Volume)
• Switchable tube/solid state rectifier; tube for “sag” and SS for “tight”
• Switchable negative feedback; choose between stock 5G9 (no NFB), 5F6-A or 6G3
• Beautiful, swampy bias-vary tremolo
• Metro spec “Zero-Loss” FX loop upgrade available (+ $195)
• Adjustable bias pot on underside/inside of chassis
• 4/8/16 ohm selector switch

Fullerton™ 5G9 Components & Specifications*:

• “Big Box” narrow panel tweed cab beautifully relic’d by Will Dyke at Armadillo Amp Works
• (1) Weber 12A125 12″ 30W Alnico speaker, inspired by the legendary Jensen P12Q
• Custom wound Heyboer output transformer using M6 gain oriented iron laminates, based on the legendary 20W Schumacher 125A1A that went on to be used on the 6G3 Brown Deluxe and others.
• Heyboer custom wound power transformer; M6 iron, vintage spec and voltage adjusted based on the Triad 8087; this PT can also be used with 5881 and 6L6GC power tubes
• Hammond 194B 4H 90mA choke
• Old-school hand wired construction with our custom-made G10FR ‘glass eyelet boards
• Jupiter “Red Astron” & Mallory 150 coupling capacitors
• Sprague, F&T electrolytic capacitors
• Carbon composition, and metal oxide resistors used in key locations for vintage tone and maximum reliability
• Belton sockets, Carling switches, Cliff jacks
• CTS, Bourns and PEC potentiometers
• 18 watts, (2) matched EH 6V6GT’s; (1) EH 5U4GB (1) TAD 12AY7, (2) JJ 12AX7’s, (1) Sovtek 12AX7PS
• Heavy Duty 16AWG 8′ power cord
• 35 lbs.
