Details from Rare Waves:
"Set the two manually tuned oscillators for any harmonic interval, and blend them together with the crossfade mixer knob. The dark and deep resonating filter seems to grab hold of the overtones from the oscillators. The tone mutates and evolves as the LFO moves the filter in droney minimal rhythm patterns.
The oscillators are tunable over a range of 20-360 Hz. They are very stable and give slowly shifting beat frequencies when set to near-unison.
The LFO section is controlled with 4 knobs and 2 switches. It generates sweeps, blips, and square wave modulations to animate the filter. The LFO has a phase-locked loop (PLL) like the original ammo can model. A rotary switch selects 2,4,8, or 16 square wave pulses per LFO sweep. The PLL automatically adjusts the timing so the square wave is locked in rhythm with the filter sweep. It creates a 4/4 meter feel that makes a nice backdrop for improvisation.
It looks like an effect pedal, but the footswitch works differently. Tapping the footswitch mutes/un-mutes the sound. Or it can trigger a fade-in or fade-out. It is a hands-free way to bring in the sound during specific sections in a performance. It also works fine as a tabletop instrument.
With some synths, if you turn the knobs randomly, you might enter a zone of high pitched, tweeter-shredding sounds. But its almost impossible to totally trainwreck in tinnitus town with this synth's dark low end sound.
Requires 9V battery or AC adapter (Boss-type 9VDC tip negative, the standard pedalboard type). Its OK to use a daisy-chain cable with other pedals that have compatible power requirements. An AC adapter is included. It has US-style pins, and accepts 100-240VAC input, so its OK to connect it to Europe and UK outlets with a slip-on travel adapter.
Audio Out: ¼" Analog mono.
CV connections (3.5mm): Filter CV In, Clock Out (analog square wave 1 pulse per step), Gate In, Audio In
The Audio In jack mutes the internal oscillators when patched. (There is no dry signal path from Audio In to Audio Out. The footswitch isn't a wet/dry bypass for Audio In)
This synth does not support V/oct or Clock In."
This item is sold As-Described
This item is sold As-Described and cannot be returned unless it arrives in a condition different from how it was described or photographed. Items must be returned in original, as-shipped condition with all original packaging.Learn More.
Listed | a month ago |
Condition | Very Good (Used) Very Good items may show a few slight marks or scratches but are fully functional and in overall great shape.learn more |
Brand | |
Model | |
Finish | |
Categories | |
Year | |
Made In |
|
