Solid State Logic SSL X-Rack XR-425 EQ Module - Used from Timbaland Bus

The Solid State Logic X-Rack EQ Module is a direct copy of the XL 9000 K Equalizer as used on Duality & AWS 900+ consoles. With E and G characteristic switching, the EQ Module can switch the high and low bands between shelving and fixed Q bell curves.

The Solid State Logic X-Rack EQ Module is the classic SSL four-band parametric EQ that is a superb all round frequency adjustment tool kit. Whether you need pinpoint accuracy for surgical problem solving, smoother broader sound shaping or a little more aggressive character the Solid State Logic X-Rack EQ Module will give you what you need. This is a fully featured EQ with high- and low-bands switchable between shelving or fixed Q bell curves and two mid-bands each with variable Q control.

Solid State Logic X-Rack EQ Module Features

• Direct copy of the XL 9000 K Equaliser as used on Duality & AWS 900+ consoles
• E and G characteristic switching
• High and low-bands switchable between shelving and fixed Q bell curves
• Switchable between SSL E and G series console channel EQ characteristics
• EQ IN switch for A/B comparison
• Rear panel connections on balanced XLR
• TotalRecallTM status LEDs

Solid State Logic X-Rack EQ Module Specifications

• Physical:
  • Depth: 200mm / 7.9 inches (Including Front Panel Knobs, Excluding Connectors), 275mm / 10.9 inches (Including Front Panel Knobs and Connectors)
  • Height: 171mm / 6.75 inches
  • Width: 35mm / 1.4 inches (Front/Rear Panels), 49mm / 1.9 inches (Overall Width with Front and Rear Panels are Offset)
  • Weight: 260g / 9.5 Ounces
  • Boxed Size: 190mm x 290mm x 70mm / 7.5" x 11.5" x 2.5"
  • Boxed Weight: 460g / 16.5 Ounces
• EQ Curves:
  • HF Band Controls:
    • Frequency: Variable from 1.5kHz to 22kHz
    • Gain: Variable between ±20dB
    • ‘Q’: 2.5 (on ‘Bell’ Setting)
  • HMF Band Controls:
    • Frequency: Variable from 600Hz to 7kHz
    • Gain: Variable by > ±20dB
    • ‘Q’: Variable from 0.5 to 2.5 (may also vary with gain)
  • LMF Band Controls:
    • Frequency: Variable from 200Hz to 2.5kHz
    • Gain: Variable by > ±20dB
    • ‘Q’: Variable from 0.5 to 2.5 (may also vary with gain)
  • LF Band Controls:
    • Frequency: Variable from 40Hz to 600Hz
    • Gain: Variable between ±16.5dB
    • ‘Q’: 2.5 (on ‘Bell ’ Setting)
• Performance Specification:
  • THD + N: < 0.005% at +20dBu 1kHz, < 0.007% at +20dBu 10kHz
  • Frequency Response: ±0.5dB from 20Hz to 20kHz, -3dB at 200kHz
  • Output Headroom: > +26dBu at Onset of Clipping
  • Noise: < –83dBu (+4dBu Operating Level), < –92dBu (–10dBV Operating Level)

Solid State Logic X-Rack EQ Module Includes

• Solid State Logic X-Rack EQ Module
• Owners Manual
• 1 Year Warranty

Note: This Module Requires an X-Rack.
