Khan Audio VTMP - Vacuum Tube Microphone Preamp - 230V
The Khan audio VTMP is a full featured all tube microphone preamp and much more. Powered by 12AX7 and 12AU7 tubes, they are arranged in a classic feedback controlled gain block. Transformer coupled inputs and outputs are standard for full frequency response with minimal noise interference from the outside world. A rugged, high filtered power supply delivers the basis for the device.
The VTMP has a microphone gain range of 35 to 57 dB. The 20dB pad allows use with hot microphones and signal sources without clipping. It can also be used as a balanced line driver accepting nominal +4dB signals at the balanced line input jack. A high impedance instument input is also included with a thru jack for live/di use. A 6 position output pad allows the use of the overload character of the box. With a plethora of input and output configurations, the Khan VTMP can enhance your recording process.
Features:
• All Tube Signal Path
• 12AX7 and 12AU7 Tubes
• Cinemag input transformer
• Custom Output transformer
• -20dB/-10dB mic/line pad
• 12 position Gain switch in 2dB steps
• 6 position output pad in -6dB steps
• 1/4" High Impedance Instrument Input
• -12dB instrument pad (active/passive sources)
• 1/4" Instrument direct thru jack.
• Transformer Balanced Line Output
• High Headroom Gain Stage Design
• High Filtered Internal Power Supply
• Sleek Ergonomic Design
• Made in USA
Specifications:
• Instrument Input impedance 2.2M ohm
• Max Signal Input: 3v RMS (+10dB)
• Gain: 23dB - 45dB
• Frequency Response: 5Hz - 30KHz +/- 1dB
• Mic Input impedance: 1K ohm
• Max Signal Input: .7v RMS (+0dB)
• Gain: 35dB - 57dB
• Frequency Response: 15Hz - 24KHz +/- 1dB
• Line Input Impedance: 100k ohm
• Max Signal Input: 10v RMS (+20dB)
• Gain: -10dB - +14dB
• Frequency Response: 15Hz - 22KHz +/- 1dB
• THD (1KHz 0dB Input): .75%
• Signal to Noise: > -92dB
• Size: 216 x 133 x 63.5 mm
• Voltage: 220V
• Weight: 2.72 Kg
Khan Audio VTMP - Vacuum Tube Microphone Preamp - 230V
The Khan audio VTMP is a full featured all tube microphone preamp and much more. Powered by 12AX7 and 12AU7 tubes, they are arranged in a classic feedback controlled gain block. Transformer coupled inputs and outputs are standard for full frequency response with minimal noise interference from the outside world. A rugged, high filtered power supply delivers the basis for the device.
The VTMP has a microphone gain range of 35 to 57 dB. The 20dB pad allows use with hot microphones and signal sources without clipping. It can also be used as a balanced line driver accepting nominal +4dB signals at the balanced line input jack. A high impedance instument input is also included with a thru jack for live/di use. A 6 position output pad allows the use of the overload character of the box. With a plethora of input and output configurations, the Khan VTMP can enhance your recording process.
Features:
• All Tube Signal Path
• 12AX7 and 12AU7 Tubes
• Cinemag input transformer
• Custom Output transformer
• -20dB/-10dB mic/line pad
• 12 position Gain switch in 2dB steps
• 6 position output pad in -6dB steps
• 1/4" High Impedance Instrument Input
• -12dB instrument pad (active/passive sources)
• 1/4" Instrument direct thru jack.
• Transformer Balanced Line Output
• High Headroom Gain Stage Design
• High Filtered Internal Power Supply
• Sleek Ergonomic Design
• Made in USA
Specifications:
• Instrument Input impedance 2.2M ohm
• Max Signal Input: 3v RMS (+10dB)
• Gain: 23dB - 45dB
• Frequency Response: 5Hz - 30KHz +/- 1dB
• Mic Input impedance: 1K ohm
• Max Signal Input: .7v RMS (+0dB)
• Gain: 35dB - 57dB
• Frequency Response: 15Hz - 24KHz +/- 1dB
• Line Input Impedance: 100k ohm
• Max Signal Input: 10v RMS (+20dB)
• Gain: -10dB - +14dB
• Frequency Response: 15Hz - 22KHz +/- 1dB
• THD (1KHz 0dB Input): .75%
• Signal to Noise: > -92dB
• Size: 216 x 133 x 63.5 mm
• Voltage: 220V
• Weight: 2.72 Kg
